ADE-208-160B(Z)
HRW36F
Silicon Schottky Barrier Diode
for High Frequency Rectifying
Rev. 2
Nov. 1994
Features
鈥?Low forward voltage drop. (V
F
=0.80V max)
鈥?High reverse voltage. (V
R
=90V max)
鈥?Full molded fin enables easy insulation from
heat sink.
1
2
3
Pin Arrangement
Ordering Information
Type No.
HRW36F
Laser Mark
HRW36F
Package Code
TO-220FM
1 2
3
1 Anode
2 Cathode
3 Anode
Absolute Maximum Ratings
(Ta = 25擄C)
*
Item
Repetitive peak reverse voltage
Average forward current
Non-Repetitive peak forward surge current
Symbol
V
RRM
I
o
**
I
FSM
***
T
j
T
stg
Value
90
10
70
125
-40 to +125
Unit
V
A
A
擄C
擄C
Junction temperature
Storage temperature
* Per one device
** Square wave, Duty (1/2), Tc=95擄C, Sum of two devices
*** Half sine wave 10msec
Electrical Characteristics
(Ta = 25擄C)
*
Item
Forward voltage
Reverse current
*
Per one device
Symbol
V
F1
V
F2
I
R
Min
鈥?/div>
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
Max
0.6
V
0.8
4.0
mA
Unit
Test Condition
I
F
= 2.0 A
I
F
= 4.0 A
V
R
= 90 V
