HPP804B130 Datasheet

  • HPP804B130

  • TEMPERATURE AND RELATIVE HUMIDITY SENSOR

  • 4頁

  • HUMIREL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TECHNICAL
1
DATA
TEMPERATURE AND RELATIVE HUMIDITY SENSOR
HTS2030SMD
Meets RoHS regulations
Based on a unique
capacitive cell for humidity
measurement and a
Negative
Temperature Coefficient (NTC)
thermistor for temperature measurement, this dual purpose
relative humidity / temperature miniaturized sensor is designed for high volume,
cost
sensitive applications with tight space constraints.
It is useful in all applications where
dew point, absolute humidity measurements
or humidity compensation are required.
M
AIN FEATURES
鈼?/div>
Miniature Surface mount SMD package.
鈼?/div>
Lead free components.
鈼?/div>
Full interchangeability
with no calibration required in standard conditions.
鈼?/div>
Instantaneous desaturation
after long periods in saturation phase.
鈼?/div>
Compatible with automatized assembly processes,
including Pb free
wave soldering and reflow processes
(1)
鈼?/div>
High reliability and long term stability.
鈼?/div>
Patented solid polymer structure.
鈼?/div>
Suitable for linear voltage or frequency output circuitry.
鈼?/div>
Fast response time and very low temperature coefficient.
鈼?/div>
Part may be washed with distilled water.
鈼?/div>
Individual marking for compliance to stringent traceability requirements.
(1)
soldering temperature profiles available on request / contact us at
application@humirel.com
Operating Range
100
M
AXIMUM RATINGS
Ratings
Symbol
Value
Unit
Relative Humidity in % RH
90
80
Operating Temperature
Storage Temperature
Supply Voltage (Peak)
Humidity Operating Range
Ta
Tstg
Vs
RH
-60 to 140
-60 to 140
10
0 to 100
擄C
擄C
Vac
% RH
70
60
50
40
30
20
10
0
-60
-40
-20
0
20
40
60
80
100
120
140
160
Temperature in 擄C
C
HARACTERISTICS
Humidity sensor (
Ta = 25擄C, measurement frequency @ 10kHz unless otherwise noted
)
Characteristics
Symbol
Min.
Typ.
Max.
Unit.
Humidity measuring range
Supply voltage
Nominal capacitance @ 55% RH*
Temperature coefficient
Averaged Sensitivity from 33% to 75% RH
Leakage current (Vcc = 5 Volts)
Recovery time after 150 hours of condensation
Humidity Hysteresis
Long term stability
Time constant (33 to 80 % RH, still air @ 63%)
Deviation to typical response curve (10% to 90%) RH)
RH
Vs
C
Tcc
鈭咰
/% RH
I
tr
1
99
10
%RH
V
pF
pF/擄C
pF/% RH
177
180
183
0.01
0.31
1
10
+/-1
nA
s
%RH
%RH/yr
s
%RH
蟿
ta
+/-0.5
3
+/-2
5
*tighter specification available on request
HUMIREL HPC055 Rev0 June 2004
HTS2030SMD
