HS1101LF Relative Humidity
Sensor
DESCRIPTION
Based on a unique capacitive cell, these relative
humidity sensors are designed for high volume,
cost sensitive applications such as office
automation, automotive cabin air control,
home appliances, and industrial process control
systems. They are also useful in all applications
where humidity compensation is needed.
FEATURES
!
Lead Free Components
!
Full Interchangeability with no
calibration required in standard
conditions
!
Instantaneous desaturation after long
periods in saturation phase
!
Compatible with automatized
assembly processes, including Pb free
wave soldering and reflow processes
(1)
!
High Reliability and Long Term
Stability
!
Suitable for linear voltage or
frequency output circuitry
!
Fast response time and very low
temperature coefficient
!
Part may be washed with distilled
water
!
Individual marking for compliance to
stringent traceability requirements
(1) Soldering temperature profiels available upon
request/contact us at application@humirel.com
Relative Humidity in % RH
100
90
maximum ratings
Ratings
Operating Temperature
Storage Temperature
Supply Voltage (Peak)
Humidity Operating Range
Symbol
Ta
Tstg
Vs
RH
Value
-60 to 140
-60 to 140
10
0 to 100
Unit
擄C
擄C
Vac
% RH
Operating Range
!
Patented Solid Polymer Structure
80
70
60
50
40
30
20
10
0
-60
-40
-20
0
20
40
60
80
100
120
140
160
Temperature in 擄C
Measurement Specialties, Inc.
G
1000 Lucas Way Hampton, VA 23666 USA
G
www.meas-spec.com
G
757-766-1500
G
800-745-8008
G
Fax 757-766-4297
-1-
