HMC429LP4 Datasheet

  • HMC429LP4

  • MMIC VCO w/ BUFFER AMPLIFIER, 4.45 - 5.0 GHz

  • 6頁

  • HITTITE

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MICROWAVE CORPORATION
v01.0604
HMC429LP4
MMIC VCO w/ BUFFER
AMPLIFIER, 4.45 - 5.0 GHz
Features
Pout: +4.0 dBm
Phase Noise: -105 dBc/Hz @100 KHz
No External Resonator Needed
Single Supply: 3V @ 30 mA
QFN Leadless SMT Package, 16 mm
2
Typical Applications
Low noise MMIC VCO w/Buffer Ampli鏗乪r for:
鈥?802.11a, HiperLAN WLAN
鈥?VSAT, UNII & Microwave Radio
鈥?Test Equipment & Industrial Controls
鈥?Military
Functional Diagram
General Description
The HMC429LP4 is a GaAs InGaP Heterojunc-
tion Bipolar Transistor (HBT) MMIC VCO with
integrated resonator, negative resistance device,
varactor diode, and buffer ampli鏗乪r. Covering
4.45 to 5.0 GHz, the VCO鈥檚 phase noise per-
formance is excellent over temperature, shock,
vibration and process due to the oscillator鈥檚
monolithic structure. Power output is 4.0 dBm
typical from a single supply of 3.0V @ 30mA.
The voltage controlled oscillator is packaged in a
low cost leadless QFN 4 x 4 mm surface mount
package.
15
VCOs - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C, Vcc = +3V
Parameter
Frequency Range
Power Output
SSB Phase Noise @ 100 kHz Offset, Vtune= +5V @ RF Output
Tune Voltage (Vtune)
Supply Current (Icc) (Vcc = +3.0V)
Tune Port Leakage Current
Output Return Loss
Harmonics
2nd
3rd
Pulling (into a 2.0:1 VSWR)
Pushing @ Vtune= +5V
Frequency Drift Rate
6
0
30
10
1.0
Min.
Typ.
4.45 - 5.0
4.0
-105
10
Max.
Units
GHz
dBm
dBc/Hz
V
mA
碌A(chǔ)
dB
-11
-23
10
14
0.4
dBc
dBc
MHz pp
MHz/V
MHz/擄C
15 - 72
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
12 Elizabeth Drive, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order Online at www.hittite.com
