HMC395
InGaP HBT GAIN BLOCK
MMIC AMPLIFIER, DC - 4.0 GHz
Features
Gain: 15 dB
P1dB Output Power: +16 dBm
Stable Gain Over Temperature
50 Ohm I/O鈥檚
1
AMPLIFIERS - CHIP
Typical Applications
An excellent cascadable 50 Ohm
Gain Block or LO Driver for:
鈥?Microwave & VSAT Radios
鈥?Test Equipment
鈥?Military EW, ECM, C I
鈥?Space Telecom
3
Small Size: 0.38 mm x 0.58 mm x 0.1 mm
Functional Diagram
General Description
The HMC395 die is a GaAs InGaP Heterojunction
Bipolar Transistor (HBT) Gain Block MMIC DC - 4
GHz ampli鏗乪r. This ampli鏗乪r die can be used as ei-
ther a cascadable 50 Ohm gain stage or to drive the
LO of HMC mixers with up to +17dBm output power.
The HMC395 offers 16 dB of gain and an output IP3
of +31dBm while requiring only 54mA from a +5V
supply. The Darlington feedback pair used results
in reduced sensitivity to normal process variations
and yields excellent gain stability over temperature
while requiring a minimal number of external bias
components. The HMC395 can easily be integrated
into Multi-Chip-Modules (MCMs) due to its small
(0.22mm
2
) size. All data is with the chip in a 50 Ohm
test 鏗亁ture connected via 0.025mm (1mil) diameter
wire bonds of minimal length 0.5mm (20mils).
Electrical Speci鏗乧ations,
Vs= +5.0V, Rbias= 22 Ohm, T
A
= +25擄 C
Parameter
Gain
DC - 1.0 GHz
1.0 - 4.0 GHz
DC - 1.0 GHz
1.0 - 4.0 GHz
DC - 1.0 GHz
1.0 - 4.0 GHz
DC - 1.0 GHz
1.0 - 4.0 GHz
DC - 4.0 GHz
DC - 1.0 GHz
1.0 - 2.0 GHz
2.0 - 4.0 GHz
DC - 1.0 GHz
1.0 - 2.0 GHz
2.0 - 4.0 GHz
DC - 4.0 GHz
Min.
Typ.
16
15
0.004
0.008
18
15
17
10
19
16
15
10
31
28
22
4.5
54
Max.
Units
dB
dB
dB/ 擄C
dB/ 擄C
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
dBm
dBm
dB
mA
Gain Variation Over Temperature
Input Return Loss
Output Return Loss
Reverse Isolation
Output Power for 1 dB Compression (P1dB)
Output Third Order Intercept (IP3)
Noise Figure
Supply Current (Icq)
Note: Data taken with broadband bias tee on device output.
