MICROWAVE CORPORATION
v00.0303
HMC322
Features
Broadband Performance: DC - 10.0 GHz
High Isolation: >38 dB@ 4 GHz
Low Insertion Loss: 2.0 dB@ 4 GHz
Integrated 3:8 TTL Decoder
Small Size: 1.45 mm x 1.6 mm x 0.10 mm
GaAs MMIC SP8T NON-REFLECTIVE
SWITCH, DC - 10.0 GHz
Typical Applications
The HMC322 is ideal for:
鈥?Telecom Infrastructure
鈥?Microwave Radio & VSAT
鈥?Military & Space
鈥?Test Instrumentation
Functional Diagram
General Description
The HMC322 is a broadband non-re鏗俥ctive
GaAs MESFET SP8T switch chip. Covering DC
to 10.0 GHz, this switch offers high isolation and
low insertion loss and extends the frequency
coverage of Hittite鈥檚 SP8T switch product line.
This switch also includes an on board binary
decoder circuit which reduces the required logic
control lines to three. The switch operates using
a negative control voltage of 0/-5V, and requires
a 鏗亁ed bias of -5V. All data is tested with the chip
in a 50 Ohm test 鏗亁ture connected via 0.025 mm
(1 mil) diameter wire bonds of 0.5 mm (20 mils)
length.
7
SWITCHES - CHIP
Electrical Speci鏗乧ations,
T
A
= +25擄 C, With 0/-5V Control, Vee= -5V, 50 Ohm System
Parameter
Frequency
DC - 2.0 GHz
DC - 4.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
DC - 10.0 GHz
DC - 2.0 GHz
DC - 4.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
DC - 10.0 GHz
鈥淥n State鈥?/div>
鈥淥ff State鈥?/div>
DC - 10.0 GHz
DC - 10.0 GHz
0.5 - 10.0 GHz
0.5 - 10.0 GHz
DC - 10.0 GHz
50
150
ns
ns
19
34
40
32
27
20
18
Min.
Typ.
1.9
2.0
2.1
2.2
2.4
46
38
32
26
24
14
11
23
38
Max.
2.3
2.4
2.5
2.6
2.8
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
Insertion Loss
Isolation (RFC to RF1 - 8)
Return Loss
Return Loss
Input Power for 1 dB Compression
Input Third Order Intercept
(Two-Tone Input Power = +7 dBm Each Tone)
Switching Characteristics
tRISE, tFALL (10/90% RF)
tON, tOFF (50% CTL to 10/90% RF)
7 - 14
