HMC320MS8G Datasheet

  • HMC320MS8G

  • GaAs MMIC LOW NOISE AMPLIFIER , 5.0 - 6.0 GHz

  • 237.52KB

  • 6頁

  • HITTITE

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

v00.0900
MICROWAVE CORPORATION
HMC320MS8G
GaAs MMIC LOW NOISE
AMPLIFIER , 5.0 - 6.0 GHz
Features
Selectable Functionality:
LNA, Driver, or LO Buffer Amp
Adjustable Input IP3 Up to +10 dBm
+3V Operation
Ultra Small 8 Lead MSOP:
14.8 mm
2
x 1mm High
8
AMPLIFIERS - SMT
Typical Applications
The HMC320MS8G is ideal for:
鈥?UNII
鈥?HiperLAN
Functional Diagram
General Description
The HMC320MS8G is a low cost C-band 鏗亁ed
gain Low Noise Ampli鏗乪r (LNA). The HMC320MS8G
operates using a single positive supply that can be
set between +3V and +5V. With +3V bias, the LNA
provides a noise 鏗乬ure of 2.5dB, 12dB gain and
better than 10dB return loss across the UNII band.
The HMC320MS8G also features adaptive baising
that allows the user to select the optimal P1dB
performance for their system using an external set
resistor on the 鈥淩ES鈥?pin. P1dB performance can
be set between a range of +1 dBm to +13dBm. The
low cost LNA uses an 8-leaded MSOP ground base
surface mount plastic package, which occupies less
than 14.8mm
2
.
Electrical Speci鏗乧ations,
T
A
= +25擄 C, Vdd = +3V
Parameter
Low Power*
(VSET = 0V, Idd = 7 mA)
Min.
Frequency Range
Gain
Gain Variation over Temperature
Gain Flatness
Noise Figure
Input Return Loss
Output Return Loss
Output Power for 1 dB Compression (P1dB)
Input Third Order Intercept Point (IIP3)
Supply Current (Idd)
4
7
-4
-3
8
Typ.
5-6
10
0.025
鹵0.5
2.7
10
13
-1
1
7
3.8
4
10
6
4
16
0.035
8
Max.
Medium Power*
(VSET = 3V, Idd = 25 mA)
Min.
Typ.
5-6
12
0.025
鹵1.0
2.5
10
18
9
8
25
3.8
4
10
9
6
16
0.035
9
Max.
High Power*
(VSET = 3V, Idd = 40 mA)
Min.
Typ.
5-6
13
0.025
鹵1.5
2.6
10
20
12
10
40
3.8
16
0.035
Max.
GHz
dB
dB/擄C
dB
dB
dB
dB
dBm
dBm
mA
Units
* R
BIAS
resistor value sets current. See adaptive biasing application note.
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
12 Elizabeth Drive, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order Online at www.hittite.com
8 - 92

HMC320MS8G 產品屬性

  • 0現貨

  • 停產

  • -

  • 帶

  • 停產

  • 5GHz ~ 6GHz

  • 9dBm

  • 12dB

  • 2.5dB

  • HiperLAN，UNII

  • 3V

  • 25mA

  • -

  • 表面貼裝型

  • 8-TSSOP，8-MSOP（0.118"，3.00mm 寬）裸露焊盤

  • 8-MSOP-EP
