HMC314 Datasheet

  • HMC314

  • GaAs InGaP HBT MMIC DRIVER AMPLIFIER, 0.7 - 4.0 GHz

  • 6頁

  • HITTITE

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MICROWAVE CORPORATION
v02.0802
HMC314
GaAs InGaP HBT MMIC DRIVER
AMPLIFIER, 0.7 - 4.0 GHz
Features
P1dB Output Power: +18 dBm
Output IP3: +29 dBm
Gain: 12 dB
Single Supply: 5V
Ultra Small Package: SOT26
8
AMPLIFIERS - SMT
Typical Applications
Ideal Broadband Gain Stage for:
鈥?2.2 - 2.7 GHz MMDS
鈥?3.5 GHz Wireless Local Loop
鈥?Low Pro鏗乴e Portable Wireless Devices
鈥?WLAN Systems
Functional Diagram
General Description
The HMC314 is a GaAs InGaP Heterojunction Bipo-
lar Transistor (HBT) MMIC ampli鏗乪r that operates
from a single positive supply. This ampli鏗乪r also
incorporates a power down feature. When the 鈥淰pd鈥?/div>
pin is held low, the ampli鏗乪r will shut down. The
surface mount SOT26 ampli鏗乪r can be used as a
broadband gain stage for wideband applications.
The ampli鏗乪r provides 12 dB of gain and +22 dBm
of saturated power while operating from a single
positive +5v supply. The HMC314 is packaged in
an ultra small SOT26 package at a height of only
1.45mm.
Electrical Speci鏗乧ations,
T
A
= +25擄 C
Vs = +5V, Rbias = 10 Ohm
Parameter
Min.
Frequency Range
Gain
Gain Variation Over Temperature
Input Return Loss
Output Return Loss
Reverse Isolation
Output Power for 1 dB Compression (P1dB) @ 1 GHz
Saturated Output Power (Psat) @ 1 GHz
Output Third Order Intercept (IP3) @ 1 GHz
Switching Speed
Supply Current (Icc)
Control Voltage (Vpd)
Control Current (Ipd)
On/Off
6
2
22
15
19
26
7
Typ.
0.7 - 4.0
12
0.015
12
6
30
18
22
29
60
150
0/5
.001/12
16
0.025
Max.
GHz
dB
dB/擄C
dB
dB
dB
dBm
dBm
dBm
ns
mA
Volts
mA
Units
8 - 74
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
12 Elizabeth Drive, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order Online at www.hittite.com
