HMC292LM3C Datasheet

  • HMC292LM3C

  • GaAs MMIC DOUBLE-BALANCED SMT MIXER, 17 - 31 GHz

  • 278.09KB

  • 8頁

  • HITTITE

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

v00.0302
MICROWAVE CORPORATION
HMC292LM3C
GaAs MMIC DOUBLE-BALANCED
SMT MIXER, 17 - 31 GHz
Typical Applications
The HMC292LM3C is ideal for:
鈥?Microwave Point to Point Radios
鈥?Multi-Point/LMDS Radios
鈥?SATCOM
Features
Input IP3: +19 dBm
LO / RF Isolation: 25 to 40 dB
Passive: No DC Bias Required
Leadless SMT Package, 25mm
2
Functional Diagram
General Description
The HMC292LM3C is a 17 - 31 GHz surface
mount passive GaAs MMIC double-balanced
mixer in a SMT leadless chip carrier package.
The mixer can be used as a downconverter or
upconverter. Excellent isolations are provided by
on-chip baluns, which require no external com-
ponents and no DC bias. All data is with the non-
hermetic, epoxy sealed LM3C packaged device
mounted in a 50 Ohm test 鏗亁ture. Utilizing the
HMC292LM3C eliminates the need for wirebond-
ing, thereby providing a consistent connection
interface for the customer.
12
MIXERS - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C
LO= +13 dBm, IF= 1 GHz
Parameter
Min.
Frequency Range, RF & LO
Frequency Range, IF
Conversion Loss
Noise Figure (SSB)
LO to RF Isolation
LO to IF Isolation
RF to IF Isolation
IP3 (Input)
IP2 (Input)
1 dB Gain Compression (Input)
26
20
22
17
45
8
Typ.
18 - 28
DC - 6
7.5
7.5
35
25
33
19
50
12
9.5
9.5
Max.
LO= +13 dBm, IF= 1 GHz
Units
Min.
Typ.
17 - 31
DC - 6
8
8
21
20
20
15
42
8
32
25
30
19
50
12
11
11
Max.
GHz
GHz
dB
dB
dB
dB
dB
dBm
dBm
dBm
12 - 114
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
12 Elizabeth Drive, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order Online at www.hittite.com

HMC292LM3C 產品屬性

  • 0現貨

  • 停產

  • -

  • 帶

  • 停產

  • 通用

  • 17GHz ~ 31GHz

  • 1

  • -

  • 8dB

  • 升/降頻器

  • -

  • -

  • 表面貼裝型

  • 6-TQFN 裸露焊盤

  • 6-SMT（5.08x5.08）

HMC292LM3C相關型號PDF文件下載
