MICROWAVE CORPORATION
v01.0300
HMC266
GaAs MMIC SUB-HARMONICALLY
PUMPED MIXER, 20 - 40 GHz
Typical Applications
The HMC266 is ideal for:
鈥?23, 26, & 38 GHz Point to Point Radios
鈥?LMDS
鈥?SATCOM
Features
Input IP3: Up to +17 dBm
Sub-Harmonically Pumped (x2) LO
Small Size: 1.32mm x 1.47mm
Functional Diagram
General Description
The HMC266 chip is a broadband GaAs MMIC
sub-harmonically pumped (x2) balanced passive
mixer which can be used as an upconverter or
downconverter in a small overall chip area of 1.9
mm
2
. The 2LO to RF isolation is excellent elimi-
nating the need for additional 鏗乴tering. All data is
with the chip in a 50 ohm test 鏗亁ture connected
via 0.076 mm (3 mil) ribbon bonds of minimal
length <0.31 mm (<12 mils). These devices are
much smaller and more reliable than hybrid diode
mixer designs.
5
MIXERS - CHIP
Electrical Speci鏗乧ations,
T
A
= +25擄 C, LO Drive = +12 dBm
IF = 1 GHz
Parameter
Min.
Frequency Range, RF
Frequency Range, LO
Frequency Range, IF
Conversion Loss
Noise Figure (SSB)
2LO to RF Isolation
LO to RF Isolation
2LO to IF Isolation
RF to IF Isolation
LO to IF Isolation
IP3 (Input)
1 dB Compression (Input)
42
20
50
16
48
10
0
Typ.
20 - 40
10 - 20
1-3
12
12
52
24
60
22
55
13
+4
16
16
Max.
GHz
GHz
GHz
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
Units
5 - 64
For price, delivery, and to place orders, please contact Hittite Microwave Corporation:
12 Elizabeth Drive, Chelmsford, MA 01824 Phone: 978-250-3343 Fax: 978-250-3373
Order Online at www.hittite.com
