HMC241QS16
Features
Low Insertion Loss (2 GHz): 0.5 dB
Single Positive Supply: Vdd = +5V
Integrated 2:4 TTL Decoder
16 Lead QSOP Package
GaAs MMIC SP4T NON-REFLECTIVE
SWITCH, DC - 3.5 GHz
Typical Applications
The HMC241QS16 is ideal for:
鈥?Base Stations & Portable Wireless
鈥?CATV / DBS
鈥?Wireless Local Loop
鈥?Test Equipment
Functional Diagram
General Description
The HMC241QS16 is a low-cost non-re鏗俥ctive
SP4T switch in a 16-lead QSOP package. Cover-
ing DC - 3.5 GHz, this switch offers high isolation
and has a low insertion loss of 0.5 dB at 2 GHz.
The switch offers a single positive bias and true
TTL/CMOS compatibility. A 2:4 decoder is inte-
grated on the switch requiring only 2 control lines
and a positive bias to select each path, replacing
8 control lines normally required by GaAs SP4T
switches.
14
SWITCHES - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C, For TTL Control and Vdd = +5V in a 50 Ohm System
Parameter
Frequency
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.5 GHz
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.5 GHz
鈥淥n State鈥?/div>
DC - 2.5 GHz
DC - 3.5 GHz
0.3 - 3.5 GHz
0.5 - 2.5 GHz
0.3 - 3.5 GHz
0.3 - 3.5 GHz
0.3 - 3.5 GHz
tRISE, tFALL (10/90% RF)
tON, tOFF (50% CTL to 10/90% RF)
40
150
ns
ns
40
32
28
23
17
9
8
12
22
40
Min.
Typ.
0.5
0.5
0.6
1.0
45
36
32
26
21
12
12
16
25
44
Max.
0.8
0.8
0.9
1.5
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
Insertion Loss
Isolation
Return Loss
Return Loss
Input Power for 1dB Compression
Input Third Order Intercept
(Two-Tone Input Power = +7 dBm Each Tone)
Switching Characteristics
RF1-4 鈥淥ff State鈥?/div>
14 - 124
