v02.1203
MICROWAVE CORPORATION
HMC232C8
GaAs MMIC SMT HIGH ISOLATION
SPDT SWITCH, DC - 8.0 GHz
Features
Isolation: 55 dB @ 2.0 GHz
43 dB @ 6.0 GHz
Insertion Loss: 1.6 dB Typical @ 6.0 GHz
Non-Re鏗俥ctive Design
Surface Mount Ceramic Package
Direct Replacement for HMC132C8
Typical Applications
The HMC232C8 is ideal for:
鈥?Telecom Infrastructure
鈥?Microwave Radio & VSAT
鈥?Military Radios, Radar & ECM
鈥?Test Instrumentation
Functional Diagram
General Description
The HMC232C8 is a broadband high isolation
non-re鏗俥ctive GaAs MESFET SPDT switch in a
non-hermetic surface mount ceramic package.
Covering DC to 8.0 GHz, the switch features >55
dB isolation up to 2 GHz and >42 dB isolation
up to 8.0 GHz. The switch operates using
complementary negative control voltage logic
lines of -5/0V and requires no bias supply. This
product is a form, 鏗乼 & functional replacement for
the HMC132C8.
14
SWITCHES - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C, With 0/-5V Control, 50 Ohm System
Parameter
Frequency
DC - 2.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
DC - 2.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
DC - 2.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
DC - 2.0 GHz
DC - 6.0 GHz
DC - 8.0 GHz
0.5 - 8.0 GHz
0.5 - 8.0 GHz
22
40
50
38
37
Min.
Typ.
1.2
1.6
2.2
55
43
42
19
12
10
13
8
7
26
46
Max.
1.5
2.0
2.8
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
Insertion Loss
Isolation
Return Loss
鈥淥n State鈥?/div>
Return Loss RF1, RF2
鈥淥ff State鈥?/div>
Input Power for 1 dB Compression
Input Third Order Intercept
(Two-Tone Input Power= +7 dBm Each Tone, 1 MHz Tone Separation)
Switching Characteristics
tRISE, tFALL (10/90% RF)
tON, tOFF (50% CTL to 10/90% RF)
DC - 8.0 GHz
3
5
ns
ns
14 - 88
