'9

9

n

ew

!

HMC222C12

MICROWAVE CORPORATION

GaAs MMIC SP4T SWITCH NON-REFLECTIVE DC TO 6.0 GHz

F

EBRUARY

2001

V

02.0101

Features

SINGLE POSITIVE SUPPLY: Vdd = +5V

INTEGRATED 2:4 TTL DECODER

CERAMIC SMT PACKAGE

General Description

flective SP4T switch in a ceramic surface

mount package. This SP4T switch covers

RF telecom/datacom bands from DC - 6

GHz. The switch offers a single positive

bias and true TTL/CMOS compatibility. A

2:4 decoder is integrated on the switch re-

quiring only 2 control lines and a +5V bias to

select each path. An input IP3 of +40 dBm

helps maintain the best possible dynamic

range in receiver & test instrument applica-

tions. The integrated 2:4 TTL/CMOS de-

coder replaces 8 control lines normal re-

quired by GaAs SP4T switches.

BROADBAND PERFORMANCE: DC to 6GHz

The HMC222C12 is a broadband non-re-

7

Guaranteed Performance

S

WITCHES

For TTL Control and Vdd = +5V in a 50 Ohm system, -40 to +85 deg C

Parameter

Insertion Loss

Isolation

Return Loss

Return Loss

"On State"

RF1-4 "Off State"

Frequency

DC - 1.0 GHz

DC - 2.0 GHz

DC - 6.0 GHz

DC - 1.0 GHz

DC - 2.0 GHz

DC - 6.0 GHz

DC - 2.0 GHz

DC - 6.0 GHz

0.7 - 6.0 GHz

2.0 - 6.0 GHz

0.5 - 6.0 GHz

0.5 - 6.0 GHz

0.5 - 6.0 GHz

35

150

ns

ns

Min.

Typ.

1.9

2.1

2.4

52

43

27

18

12

>10

14

20

43

Max.

2.2

2.5

2.8

Units

dB

dB

dB

dB

dB

dB

dB

dB

dB m

dB m

SMT

42

37

22

15

9

6.5

11

17

SP4T

Input Power for 1dB Compression

Input Third Order Intercept

(Two-Tone Input Power = +7dBm Each Tone)

Switching Characteristics

tRISE, tFALL (10/90% RF)

tON, tOFF (50% CTL to 10/90% RF)

12 Elizabeth Drive, Chelmsford, MA 01824

Phone: 978-250-3343

Fax: 978-250-3373

Web Site: www.hittite.com

7 - 82
