MICROWAVE CORPORATION
v01.0700
HMC197
GaAs MMIC SOT26 SPDT
SWITCH, DC - 3 GHz
Features
Low Insertion Loss: 0.4 dB
Ultra Small Package: SOT26
Input IP3: +45 dBm
Positive Control: 0/+3V @ 10 uA
Typical Applications
The HMC197 is ideal for:
鈥?MMDS & WirelessLAN
鈥?PCMCIA Wireless Cards
鈥?Portable WIreless
Functional Diagram
General Description
The HMC197 is a low-cost SPDT switch in a
6-lead SOT26 plastic package for use in general
switching applications which require very low
insertion loss and very small size. The device
can control signals from DC to 3.0 GHz and is
especially suited for 900 MHz, 1.8 - 2.2 GHz,
and 2.4 GHz ISM applications with less than 1
dB loss. The design provides exceptional inser-
tion loss performance, ideal for 鏗乴ter and receiver
switching. RF1 and RF2 are re鏗俥ctive shorts
when 鈥淥ff鈥? The two control voltages require a
minimal amount of DC current and offer compat-
ibility with most CMOS & TTL logic families. See
HMC221 for same performance in an alternate
SOT26 pin-out.
14
SWITCHES - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C, Vctl = 0/+3 to +8 Vdc, 50 Ohm System
Parameter
Frequency
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
0.5 - 1.0 GHz
0.5 - 3.0 GHz
0.5 - 1.0 GHz
0.5 - 3.0 GHz
DC - 3.0 GHz
tRISE, tFALL (10/90% RF)
tON, tOFF (50% CTL to 10/90% RF)
3
10
ns
ns
24
24
18
14
20
16
14
10
25
23
40
38
Min.
Typ.
0.4
0.45
0.7
0.8
28
28
22
18
30
22
17
13
30
29
45
43
Max.
0.7
0.8
0.9
1.1
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
Insertion Loss
Isolation
Return Loss
Input Power for 1dB Compression
(Vctl = 0/+5V)
Input Third Order Intercept
(Vctl = 0/+5V) (Two-tone Input Power = +7 dBm Each Tone)
Switching Characteristics
14 - 54
