v01.0700
MICROWAVE CORPORATION
HMC190MS8
GaAs MMIC SPDT SWITCH
DC - 3 GHz
Features
Low Insertion Loss: 0.4dB
Ultra Small Package: MSOP8
High Input IP3: +50 dBm
Positive Control: 0/+3V @ 10 uA
Typical Applications
The HMC190MS8 is ideal for:
鈥?MMDS & WirelessLAN
鈥?Portable Wireless
Functional Diagram
General Description
The HMC190MS8 is a low cost SPDT switch in
an 8-lead MSOP package. The switch can con-
trol signals from DC to 3.0 GHz. It is especially
suited for low and medium power applications
using positive control voltages. The two control
voltages require a minimal amount of DC current,
which is optimal for battery powered radio sys-
tems at 0.9, 1.9, and 2.4 GHz. The HMC190MS8
design provides exceptional third order intermod-
ulation performance of +50 dBm. The design has
been optimized for the small MSOP package, and
maintains a VSWR of better than 1.2:1 up to 2
GHz. This device is the positive control MSOP8
packaged version of our HMC239S8 negative
control device.
14
SWITCHES - SMT
Electrical Speci鏗乧ations,
T
A
= +25擄 C, Vctl = 0/+3 to +8 Vdc
Parameter
Frequency
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
DC - 1.0 GHz
DC - 2.0 GHz
DC - 2.5 GHz
DC - 3.0 GHz
0.5 - 1.0 GHz
0.5 - 3.0 GHz
0.5 - 1.0 GHz
0.5 - 3.0 GHz
DC - 3.0 GHz
tRISE, tFALL (10/90% RF)
tON, tOFF (50% CTL to 10/90% RF)
3
10
ns
ns
23
23
22
19
24
20
15
10
25
23
45
44
Min.
Typ.
0.4
0.4
0.5
0.7
27
27
26
22
28
28
20
16
30
29
50
49
Max.
0.6
0.6
0.8
1.0
Units
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
Insertion Loss
Isolation
Return Loss
Input Power for 1 dB Compression
(Vctl = 0/+5V)
Input Third Order Intercept
(Vctl = 0/+5V)(Two-tone Input Power = +7 dBm Each Tone)
Switching Characteristics
14 - 36
