HMC-AUH232
v00.0907
GaAs HEMT MMIC MODULATOR
DRIVER AMPLIFIER, DC - 43 GHz
Features
Small Signal Gain: 12 dB
Output Voltage: up to 8V pk-pk
Single-Ended I/Os
High Speed Performance: 46 GHz 3 dB Bandwidth
Low Power Dissipation: 0.9 W
Typical Applications
This HMC-ALH232 is ideal for:
鈥?40 Gb/s Lithium Niobate/ Mach Zender
Fiber Optic Modulators
AMPLIFIERS - DRIVERS - CHIP
鈥?Broadband Gain Block for Test & Measurement
Equipment
鈥?Broadband Gain Block for RF Applications
Small Die Size: 2.1 x 1.70 x 0.1 mm
鈥?Military & Space
Functional Diagram
General Description
The HMC-AUH232 is a GaAs MMIC HEMT Distributed
Driver Amplifier die which operates between DC and
43 GHz and provides a typical 3 dB bandwidth of
46 GHz. The amplifier provides 12 dB of small signal
gain while requiring only 180 mA from a +5V supply
voltage. The HMC-AUH232 exhibits very good gain
and phase ripple to 40 GHz, and can output up to
8V peak-to-peak with low jitter, making it ideal for for
use in broadband wireless, fiber optic communication
and test equipment applications. The amplifier die
occupies less than 3.6 mm2 which facilitates easy
integration into Multi-Chip-Modules (MCMs). The
HMC-AUH232 requires external bias-tee as well as
off-chip blocking components and bypass capacitors
for the DC supply lines. A gate voltage adjust, Vg2
is provided for limited gain adjustment, while Vg1a
adjusts the bias current for the device.
Electrical Specifi cations*,
T
A
= +25 擄C
Parameter
Frequency Range
0.5 - 5.0 GHz
Small Signal Gain
35 - 45 GHz
Input Return Loss
Output Return Loss
Supply Current
3 dB Bandwidth
Gain Ripple (5 to 35 GHz)
0.5 - 5.0 GHz
Group Delay Variation
[1]
5 - 30 GHz
30 - 45 GHz
43
10
12.5
10
8.5
180
46
鹵0.6
鹵14
鹵10
鹵22
鹵1
鹵20
鹵11
鹵25
225
dB
dB
dB
mA
GHz
dB
pS
pS
pS
12
Min.
Typ.
DC - 43
14
Max.
Units
GHz
dB
0-2
