Total Power Dissipation (Ta=25擄C) ....................................................................................... 1 W
鈥?/div>
Maximum Voltages and Currents (Ta=25擄C)
VCBO Collector to Base Voltage ........................................................................................ -30 V
VCES Collector to Emitter Voltage ..................................................................................... -30 V
VEBO Emitter to Base Voltage ........................................................................................... -10 V
IC Collector Current ...................................................................................................... -300 mA
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCES
BVEBO
ICBO
IEBO
*VCE(sat)
*VBE(on)
*hFE1
*hFE2
fT
Min.
-30
-30
-10
-
-
-
-
10
20
125
Typ.
-
-
-
-
-
-
-
-
-
-
Max.
-
-
-
-100
-100
-1.5
-2
-
-
-
Unit
V
V
V
nA
nA
V
V
K
K
MHz
Test Conditions
IC=-100uA
IC=-100uA
IE=-10uA
VCB=-30V
VEB=-10V
IC=-100mA, IB=-0.1mA
VCE=-5V, IC=-100mA
VCE=-5V, IC=-10mA
VCE=-5V, IC=-100mA
VCE=-5V, IC=-10mA
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
