Total Power Dissipation (Ta=25擄C) ...................................................................................... 1 W
鈥?/div>
Maximum Voltages and Currents (Ta=25擄C)
VCBO Collector to Base Voltage ...................................................................................... 300 V
VCEO Collector to Emitter Voltage ................................................................................... 300 V
VEBO Emitter to Base Voltage ............................................................................................. 6 V
IC Collector Current ...................................................................................................... 500 mA
Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICBO
IEBO
*VCE(sat)
*VBE(sat)
*hFE1
*hFE2
*hFE3
fT
Cob
Min.
300
300
6
-
-
-
-
25
40
40
50
-
Typ.
-
-
-
-
-
-
-
-
-
-
-
3
Max.
-
-
-
100
100
500
900
-
-
-
-
-
Unit
V
V
V
nA
nA
mV
mV
Test Conditions
IC=100uA
IC=1mA
IE=10uA
VCB=260V
VEB=6V
IC=20mA, IB=2mA
IC=20mA, IB=2mA
VCE=10V, IC=1mA
VCE=10V, IC=10mA
VCE=10V, IC=30mA
VCE=20V, IC=10mA, f=100MHz
VCB=20V
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
MHz
pF
