Subminiature High
Performance TS AlGaAs Red
LED Lamps
Technical Data
HLMP-P106/P156
HLMP-Q10X/Q15X
Features
鈥?Subminiature Flat Top
Package
Ideal for Backlighting and
Light Piping Applications
鈥?Subminiature Dome
Package
Diffused Dome for Wide
Viewing Angle
Non-diffused Dome for High
Brightness
鈥?Wide Range of Drive
Currents
500
碌
A to 50 mA
鈥?Ideal for Space Limited
Applications
鈥?Axial Leads
鈥?Available with lead
configurations for Surface
Mount and Through Hole
PC Board Mounting
Dome Packages
The HLMP-QXXX Series dome
lamps, for use as indicators, use
a tinted, diffused lens to provide
a wide viewing angle with high
on-off contrast ratio. High
brightness lamps use an
untinted, nondiffused lens to
provide a high luminous inten-
sity within a narrow radiation
pattern.
Lead Configurations
All of these devices are made by
encapsulating LED chips on
axial lead frames to form
molded epoxy subminiature
lamp packages. A variety of
package configuration options is
available. These include special
surface mount lead configura-
tions, gull wing, yoke lead, or Z-
bend. Right angle lead bends at
2.54 mm (0.100 inch) and 5.08
mm (0.200 inch) center spacing
are available for through hole
mounting. For more information
refer to Standard SMT and
Through Hole Lead Bend
Options for Subminiature LED
Lamps data sheet.
Description
Flat Top Package
The HLMP-PXXX Series flat top
lamps use an untinted, non-
diffused, truncated lens to
provide a wide radiation pattern
that is necessary for use in
backlighting applications. The
flat top lamps are also ideal for
use as emitters in light pipe
applications.
Technology
These subminiature solid state
lamps utilize a highly optimized
LED material technology,
transparent substrate
aluminum gallium arsenide (TS
AlGaAs). This LED technology
has a very high luminous
efficiency, capable of producing
high light output over a wide
range of drive currents (500
碌A
to 50 mA). The color is deep red
at a dominant wavelength of
644 nm deep red. TS AlGaAs is
a flip-chip LED technology, die
attached to the anode lead and
wire bonded to the cathode lead.
Available viewing angles are
75擄, 35擄, and 15擄.
