SUBMINIATURE T-3/4 LED

DIFFUSED AND CLEAR LAMPS

HIGH EFF. RED

YELLOW

GREEN

AIGaAs RED

HLMP-6305A

HLMP-6405A

HLMP-6505A

HLMP-Q105A

HLMP-Q101A

Water Clear

Water Clear

Water Clear

Water Clear

Red Diffused

MV6700A

MV6300A

MV6400A

HLMP-Q150A

HLMP-Q155A

Red Diffused

Yellow Diffused

Green Diffused

Red Diffused

Water Clear

PACKAGE DIMENSIONS

.087 (2.2)

.079 (2.0)

.024 (.6)

.016 (.4)

.276 (7.0)

MIN

FEATURES

鈥?Subminiature T-3/4 transfer molded

鈥?Low package pro鏗乴e

鈥?Axial leads

鈥?Wide viewing angle

.091 (2.3)

.083 (2.1)

鈥?SMT versions

DIA

.010 (.26)

.002 (.06)

.075 (1.9)

.063 (1.6)

.020 (.5)

.012 (.3)

.058 (1.48)

.050 (1.28)

.056 (1.44)

.048 (1.24)

DESCRIPTION

These T-3/4 subminiature LED lamps feature a square-

base, transfer molded package for surface mount

applications. A tinted diffused or water clear epoxy

lens 鈥?available in AIGaAs red, high-ef鏗乧iency red,

green, and yellow 鈥?produces wide-angle beam

emission and sharp on/off contrast. They are available

with gullwing lead bends for top mounting, as well as

yoke lead bends and Z-bends for mounting to the back

of a PCB.

.031 (.78)

.023 (.58)

CATHODE MARK

(COLOR STRIPE ON SIDE OF PACKAGE)

NOTES:

ALL DIMENSIONS ARE IN INCHES (mm).

ABSOLUTE MAXIMUM RATING

c

HLMP-Q101A

HLMP-Q105A

HLMP-Q150A

HLMP-Q155A

85

30

300

5

-20 to +100

-20 to +100

Parameter

Power Dissipation

Average Forward Current

Peak Forward Current

(1 碌S pulsewidth, 0.1% DF)

Lead Soldering Time at 260擄C

Operating Temperature

Storage Temperature

HLMP-6305A

MV6700A

135

30

90

5

-55 to +100

-55 to +100

HLMP-6405A

MV6300A

85

20

60

5

-55 to +100

-55 to +100

HLMP-6505A

MV6400A

135

30

90

5

-50 to +100

-50 to +100

Units

mW

mA

mA

sec

擄C

擄C

漏 2003 Fairchild Semiconductor Corporation

Page 1 of 6
