HFA5251 Datasheet

  • HFA5251

  • 800MHz Monolithic Pin Driver

  • Intersil   Intersil

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HFA5251
Data Sheet
September 1998
File Number 3689.4
800MHz Monolithic Pin Driver
The HFA5251 is a very high speed monolithic pin driver
solution for high performance test systems. The device will
switch at high data rates between two input voltage levels
providing variable amplitude pulses. The output impedance
is trimmed to achieve a precision 50鈩?source for impedance
matching. Two differential ECL/TTL compatible inputs control
the operation of the HFA5251, one controlling the
V
HIGH
/V
LOW
switching and the other controlling the output鈥檚
high-impedance state. The HFA5251鈥檚 800MHz data rate
makes it compatible with today鈥檚 high-speed VLSI test
systems and the +7V to -2V output swing allows testing of all
common logic families.
The HFA5251 is manufactured in Intersil鈥檚 proprietary
complementary bipolar UHF-1 process. The HFA5251 is
offered in die form. Contact your local sales representative
for packaging options.
Features
鈥?High Digital Data Rate . . . . . . . . . . . . . . . . . . . . . 800MHz
鈥?Very Fast Rise/Fall Times. . . . . . . . . . . . . . . . . . . . . 500ps
鈥?Wide Output Range . . . . . . . . . . . . . . . . . . . . . +7V to -2V
鈥?Precise 50鈩?Output Impedance
鈥?High Impedance, Three-State Output Control
Applications
鈥?IC Tester Pin Electronics
鈥?Pattern Generators
鈥?Pulse Generators
鈥?Level Comparator/Translator
Pinout
HFA5251 (DIE FORM)
Functional Diagram
INPUT
BUFFER
V
HIGH
V
CC2
DATA
DATA
HiZ
HiZ
V
LOW
INPUT
BUFFER
+
Q
+
DATA
DATA
50鈩?/div>
V
OUT
V
OUT
V
EE2
HiZ
HiZ
V
LOW
V
EE1
V
EE2
V
HIGH
V
CC1
-
Q
V
CC2
-
TRUTH TABLE FOR V
OUT
DATA
0
HiZ
0
1
V
LOW
HiZ
V
HIGH
HiZ
1
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Copyright
漏
Intersil Corporation 1999
