HE83139
HE80000 SERIES
A. HE83139 Introduction
HE83139 is a member of 8-bit Micro-controller series developed by King Billion Electronics Ltd. This
IC provides 512 pixels LCD display and built-in OP comparator can be used with light, voice,
temperature and humility sensor or used to detect the battery low. The 7-bit current-type D/A converter
and PWM drive output provide the complete speech output mechanism.
The 64K bytes ROM size can be used to store 15 seconds speech data. It can be applicable to the LCD
game, medium level educational toy, lower second voice recording system or used with external
command mode SRAM or Flash RAM for higher second voice recording etc.
The instruction sets of HE80000 series are quite easy to learn and simple to use. Only about thirty
instructions with four-type addressing mode are provided. Most of instructions take only 3 oscillator
clocks (machine cycles). The performance of HE83750S is enough for most of battery operation
system.
B. HE83139 Features
Operation Voltage:
System Clock
Clock Source:
Dual Clock System錛?/div>
2.4V ~ 5.5V
4MHz ~ 8MHz
Internal/External Fast clock, Internal/External slow clock
Normal (Fast) clock
32.768KHz ~ 8MHz
Slow clock
32.768 KHz
DUAL銆丗AST銆丼LOW銆両DLE銆丼LEEP Mode.
64K Bytes.
2K Bytes.
Operation Mode錛?/div>
Internal ROM:
Internal RAM:
Watch dog timer.
16 Bi-directional I/O ports.
512 pixels LCD driver with A, B type choice
LCD Bias : 1/5
LCD Charge Pump: 1 or 1.5 times of VDD
One 7-bits current-type DAC output.
One built-in OP comparator.
PWM device.
Built-in DTMF Generator.
Speech recognition function
Two external interrupts and three internal timer interrupts.
Two 16-bit timers.
Instruction set錛?32 instructions, 4 addressing mode. 10-bit DATA POINTER for RAM and 16-bit
TABLE POINTER for ROM.
