HE83116
HE80000 SERIES
A.HE83116 Introduction
HE83116 is a member of 8-bit Micro-controller series developed by King Billion Electronics Ltd
.
This
IC build-in 128-dot LCD driver, and also have 16-bit I/O port. The built-in OP comparator can be used
with (light銆乿oice銆乼emperature銆乭umility) sensor and used as battery low detection. And the 7-bit
current-type D/A converter and PWM device provide the complete speech output mechanism. The 64K
ROM Size can be used in the storage of speech (20 seconds at 3Kbytes per second), graphic, text etc. This
IC is applicable to the small systems such as calculating machine, perpetual calendar, digital watch etc..
The instruction set of HE83116 are quite easy to learn and simple to use. Only about thirty instructions
with four-type addressing mode are provided. Most of instructions take only 3 oscillator clocks (machine
cycles). The processing power is enough to most of battery operation system.
B.HE83116 Features
2.4V 鈥?5.5V
DC ~ 8MHz @ 5.0V
DC ~ 4MHz @ 2.4V
Internal ROM錛?/div>
64K Bytes(64K Program ROM)
Internal RAM錛?/div>
256 Bytes.
Dual Clock System
錛?/div>
Normal (Fast) clock錛?32.768K ~ 8MHz
Slow clock錛?/div>
32.768KHz
Operation Mode錛?/div>
DUAL銆丗AST銆丼LOW銆両DLE銆丼LEEP Mode.
With WDT (WATCH DOG TIMER) to prevent deadlock condition..
16 bit Bi-directional I/O port. Mask Option can select PUSH-PULL or OPEN DRAIN output mode
for each I/O pin.
One built-in OP comparator.
128 dots LCD driver (A銆丅 TYPE selectable).
One 7-bit current-type DAC output.
PWM device.
Two external interrupts and two internal timer interrupts.
Two 16-bit timer.
Instruction set錛?32 instructions, 4 addressing mode. 8-bit DATA POINTER for RAM and 16-bit
TABLE POINTER for ROM.
Operation Voltage錛?/div>
System Clock錛?/div>
1
V3.1E
