KING BILLION ELECTRONICS CO., LTD
椐?鍎?闆?瀛?鑲?錕?frac12; 鏈?闄?鍏?鍙?/div>
HE83016
HE80000 SERIES
A. HE83016 Introduction
HE83016 is a member of 8-bit Micro-controller series developed by King Billion Electronics Ltd
.
It is a
power speech controller. The built-in OP comparator can be used with (light voice temperature humility)
銆?/div>
銆?/div>
銆?/div>
sensor and used as battery low detection. And the 7-bit current-type D/A converter and PWM device
provide the complete speech output mechanism. The 512K ROM Size can be used in the storage of
speech (170 seconds at 3Kbytes per second).
The instruction set of HE83016 are quite easy to learn and simple to use. Only about thirty instructions
with four-type addressing mode are provided. Most of instructions take only 3 oscillator clocks (machine
cycles). The processing power is enough to most of battery operation system.
B. HE83016 Features
Operation Voltage錛?/div>
System Clock錛?/div>
Internal ROM錛?/div>
Internal RAM錛?/div>
Dual Clock System
錛?/div>
Operation Mode錛?/div>
2.4V 鈥?5.5V
DC ~ 8MHz @ 5.0V
DC ~ 4MHz @ 2.4V
512K Bytes(64K Program ROM, 448K Data ROM)
128 Bytes.
Normal (Fast) clock錛?32.768K ~ 8MHz
Slow clock錛?/div>
32.768KHz
DUAL銆丗AST銆丼LOW銆両DLE銆丼LEEP Mode.
With WDT (WATCH DOG TIMER) to prevent deadlock condition..
24 bit Bi-directional I/O port. Mask Option can select PUSH-PULL or OPEN DRAIN output
mode for each I/O pin.
One built-in OP comparator.
One 7-bit current-type DAC output.
PWM device.
Two external interrupts and two internal timer interrupts.
Two 16-bit timer. (Clock Source reference by Fast Clock)
Instruction set錛?32 instructions, 4 addressing mode. 7-bit
DATA POINTER
for RAM and
19-bit
TABLE POINTER
for ROM.
1
V2.4E
