KING BILLION ELECTRONICS CO., LTD
椐?鍎?闆?瀛?鑲?錕?frac12; 鏈?闄?鍏?鍙?/div>
HE83006
HE80000 SERIES
A. HE83006 Introduction
HE83006 is a member of 8-bit Micro-controller series developed by King Billion Electronics Ltd
.
It is
a power speech controller. The built-in OP comparator can be used with (light銆乿oice銆乼emperature銆?/div>
humility) sensor and used as battery low detection. And the 7-bit current-type D/A converter and PWM
device provide the complete speech output mechanism. The 256K ROM Size can be used in the storage
of speech (80 seconds at 3Kbytes per second).
The instruction set of HE83006 are quite easy to learn and simple to use. Only about thirty instructions
with four-type addressing mode are provided. Most of instructions take only 3 oscillator clocks
(machine cycles). The processing power is enough to most of battery operation system.
B.HE83006 Features
2.4V 鈥?5.5V
DC ~ 8MHz @ 5.0V
DC ~ 4MHz @ 2.4V
Internal ROM錛?/div>
256K Bytes(64K Program ROM, 192K Data ROM)
Internal RAM錛?/div>
128 Bytes.
Dual Clock System
錛?/div>
Normal (Fast) clock錛?32.768K ~ 8MHz
Slow clock錛?/div>
32.768KHz
Operation Mode錛?/div>
DUAL銆丗AST銆丼LOW銆両DLE銆丼LEEP Mode.
With WDT (WATCH DOG TIMER) to prevent deadlock condition..
24 bit Bi-directional I/O port. Mask Option can select PUSH-PULL or OPEN DRAIN output mode
for each I/O pin.
One built-in OP comparator.
One 7-bit current-type DAC output.
PWM device.
Two external interrupts and two internal timer interrupts.
Two 16-bit timer. (Clock Source reference by Fast Clock)
Instruction set錛?32 instructions, 4 addressing mode. 7-bit
DATA POINTER
for RAM and
18-bit
TABLE POINTER
for ROM.
Operation Voltage錛?/div>
System Clock錛?/div>
1
V3.1E
