HD74LVCR2245A
Octal Bidirectional Transceivers with 3鈥搒tate Outputs
REJ03D0377鈥?400
(Previous ADE-205-235B (Z))
Rev.4.00
Aug. 20, 2004
Description
The HD74LVCR2245A has eight buffers with three state outputs in a 20 pin package. When (T /
R)
is high, data flows
from the A inputs to the B outputs, and when (T /
R)
is low, data flows from the B inputs to the A outputs. A and B bus
are separated by making enable input (OE) high level.
All outputs, which are designed to sink up to 12mA, include equivalent 26
鈩?/div>
resistors to reduce overshoot and
undershoot.
Low voltage and high-speed operation is suitable at battery drive product (note type personal computer) and low power
consumption extends the life of a battery for long time operation.
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
V
CC
= 1.65 to 5.5 V
All inputs V
IH
(Max) = 5.5 V (@V
CC
= 0 to 5.5 V)
All inputs / outputs V
I / O
(Max) = 5.5 V (@V
CC
= 0 V or output off state)
Typical V
OL
ground bounce < 0.8 V (@V
CC
= 3.3 V, Ta = 25擄C)
Typical V
OH
undershoot > 2.0 V (@V
CC
= 3.3 V, Ta = 25擄C)
High output current 鹵12mA (@V
CC
= 3.0 to 5.5 V)
All outputs have equivalent 26
鈩?/div>
series resistors, so no external resistors are required
Ordering Information
Package Type
SOP鈥?0 pin (JEITA)
TSSOP鈥?0 pin
Package Code
FP鈥?0DAV
TTP鈥?0DAV
Package
Abbreviation
FP
T
Taping Abbreviation
(Quantity)
EL (2,000 pcs/reel)
ELL (2,000 pcs/reel)
Part Name
HD74LVCR2245AFPEL
HD74LVCR2245ATELL
Note: Please consult the sales office for the above package availability.
Function Table
Inputs
OE
L
L
H
H: High level
L: Low level
X: Immaterial
Z: High impedance
T/
R
L
H
X
Operation
B data to A bus
A data to B bus
Z
Rev.4.00 Aug. 20, 2004 page 1 of 9
