HD74LVCC4245A
Octal Dual-supply Bus Transceiver with configurable
output voltage with 3-state Outputs
REJ03D0380鈥?101
Rev.1.01
Apr. 13, 2005
Description
The HD74LVCC4245A has eight bus transceivers with three state outputs in a 24 pin package. When (DIR) is high,
data flows from the A inputs to the B outputs, and when (DIR) is low, data flows from the B inputs to the A outputs. A
and B bus are separated by making enable input (OE) high level. This 8-bit non-inverting bus transceiver uses two
separate power-supply rails.
And this product has two terminals (V
CCA
, V
CCB
), V
CCA
is connected with control input and a bus side, V
CCB
is
connected with B bus side. V
CCA
and V
CCB
are isolated.
The A port, V
CCA
, is dedicated to accept a 5 V supply level, and the configurable B port, which is designed to track
V
CCB
, accepts voltages from 3 V to 5 V. This allows for translation from a 3.3 V to a 5 V environment and vice versa.
Low voltage and high-speed operation is suitable at the battery drive product (note type personal computer) and low
power consumption extends the life of a battery for long time operation.
Features
鈥?/div>
This product function as level shift transceiver that change V
CCA
input level to V
CCB
output level, V
CCB
input level to
V
CCA
output level by providing different supply voltage to V
CCA
and V
CCB
.
鈥?/div>
This product is able to the power management: Turn on and off the supply on V
CCB
side with providing the supply
of V
CCA
. (Enable input (OE): High level)
鈥?/div>
V
CCA
= 4.5 V to 5.5 V, V
CCB
= 2.7 V to 5.5 V
鈥?/div>
All control input V
I
(max) = 5.5 V (@V
CCA
= 0 V to 5.5 V)
鈥?/div>
All A bus side input outputs V
I/O
(max) = 5.5 V
(@V
CCA
= 0 V or output off state)
鈥?/div>
All B bus side input outputs V
I/O
(max) = 5.5 V
(@V
CCB
= 0 V or output off state)
鈥?/div>
High output current
A bus side: 鹵24 mA (@V
CCA
= 4.5 V)
B bus side: 鹵24 mA (@V
CCB
= 2.7 V to 4.5 V)
鈥?/div>
Ordering Information
Part Name
HD74LVCC4245ATEL
Package Type
TSSOP鈥?4 pin
Package Code
(Previous Package)
PTSP0024JB鈥揂
(TTP鈥?4DBV)
Package
Abbreviation
T
Taping Abbreviation
(Quantity)
EL (1,000 pcs/reel)
Function Table
Inputs
OE
L
L
H
H: High level
L: Low level
X: Immaterial
Z: High impedance
DIR
L
H
X
Operation
B data to A bus
A data to B bus
Z
Rev.1.01 Apr. 13, 2005 page 1 of 8
