HD74LV2GT126A Datasheet

  • HD74LV2GT126A

  • Datasheet|ADE-205-677|MAR.20.02|88K

  • 89.24KB

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HD74LV2GT126A
Dual Bus Buffer with 3鈥搒tate Output
ADE-205-677 (Z)
Rev. 0
Mar. 2002
Description
The HD74LV2GT126A has dual bus buffer with 3鈥搒tate output in a 8 pin package. Output is disabled
when the associated output enable (OE) input is low. To ensure the high impedance state during power up
or power down, OE should be connected to GND through a pull-down resistor; the minimum value of the
resistor is determined by the current souring capability of the driver. Low voltage and high speed operation
is suitable for the battery powered products (e.g., notebook computers), and the low power consumption
extends the battery life.
Features
鈥?/div>
The basic gate function is lined up as hitachi uni logic series.
鈥?/div>
Supplied on emboss taping for high speed automatic mounting.
鈥?/div>
TTL compatible input level.
Supply voltage range : 4.5 to 5.5 V
Operating temperature range : 鈥?0 to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V, Output : Z)
鈥?/div>
Output current 鹵12 mA (@V
CC
= 4.5 V to 5.5 V)
鈥?/div>
All the logical input has hysteresis voltage for the slow transition.
鈥?/div>
Package type
Package type
SSOP-8 pin
Package code
TTP-8DB
Package suffix
US
Taping code
E (3,000 pcs / Reel)
