HD74LV1GW98A
Configurable Multiple鈥揊unction Gate
ADE-205-720 (Z)
Rev.0
Feb. 2003
Description
The HD74LV1GW98A has configurable multiple鈥揻unction gate in a 6 pin package. The Output state is
determined by eight patterns of 3鈥揵it input. The user can choose the logic functions AND, NAND, OR,
NOR, INVERTER, Non鈥揑nverted Buffer, Data Selector. Low voltage and high speed operation is suitable
for the battery powered products (e.g., notebook computers), and the low power consumption extends the
battery life.
Features
鈥?/div>
The basic gate function is lined up as hitachi uni logic series.
鈥?/div>
Supplied on emboss taping for high speed automatic mounting.
鈥?/div>
Supply voltage range : 1.65 to 5.5 V
Operating temperature range : 鈥?0 to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 5.5 V (@V
CC
= 0 V to 5.5 V)
All outputs V
O
(Max.) = 5.5 V (@V
CC
= 0 V)
鈥?/div>
Output current 鹵6 mA (@V
CC
= 3.0 V to 3.6 V), 鹵12 mA (@V
CC
= 4.5 V to 5.5 V)
鈥?/div>
All the logical input has hysteresis voltage for the slow transition.
鈥?/div>
Ordering Information
Part Name
HD74LV1GW98ACME
Package Type
CMPAK-6 pin
Package Code
CMPAK-6V(O)
Package
Abbreviation
CM
Taping
Abbreviation (Quantity)
E (3,000 pcs / Reel)
