HD74ALVC2G86
Dual 2-input Exclusive-OR Gates
ADE-205-614A (Z)
Rev. 1
August 2001
Description
The HD74ALVC2G86 performs the Boolean functions Y =
螒鈯旴
or Y =
AB
+ AB in positive logic. A
common application is as a true / complement element. If one of the inputs is low, the other input will be
reproduced in true form at the output. If one of the inputs is high, the signal on the other input will be
reproduced inverted form at the output. Low voltage and high speed operation is suitable for the battery
powered products (e.g., notebook computers), and the low power consumption extends the battery life.
Features
鈥?/div>
The basic gate function is lined up as hitachi uni logic series.
鈥?/div>
Supplied on emboss taping for high speed automatic mounting.
鈥?/div>
Supply voltage range : 1.2 to 3.6 V
Operating temperature range :
鈭?0
to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 3.6 V (@V
CC
= 0 V to 3.6 V)
All outputs V
O
(Max.) = 3.6 V (@V
CC
= 0 V)
鈥?/div>
Output current
鹵2
mA (@V
CC
= 1.2 V)
鹵4
mA (@V
CC
= 1.4 V to 1.6 V)
鹵6
mA (@V
CC
= 1.65 V to 1.95 V)
鹵18
mA (@V
CC
= 2.3 V to 2.7 V)
鹵24
mA (@V
CC
= 3.0 V to 3.6 V)
鈥?/div>
Package type
Package type
SSOP-8 pin
Package code
TTP-8DB
Package suffix
US
Taping code
E (3,000 pcs / Reel)
