HD74ALVC2G241
Dual Bus Buffer Noninverted with 3-state Output
ADE-205-573 (Z)
Rev.0
July. 2001
Description
The HD74ALVC2G241 has dual bus buffer noninverted with 3-state output in a 8 pin package. Two
noninverters are included in one circuit. Each circuit can be independently controlled by the enable signal
OE
or OE, which enables outputs when receiving a low or high level signal, respectively. To ensure the
high impedance state during power up or power down,
OE
should be connected to V
CC
through a pull-up
resistor; the minimum value of the resistor is determined by the current sinking capability of the driver.
Low voltage and high speed operation is suitable for the battery powered products (e.g., notebook
computers), and the low power consumption extends the battery life.
Features
鈥?/div>
The basic gate function is lined up as hitachi uni logic series.
鈥?/div>
Supplied on emboss taping for high speed automatic mounting.
鈥?/div>
Supply voltage range : 1.2 to 3.6 V
Operating temperature range :
鈭?0
to +85擄C
鈥?/div>
All inputs V
IH
(Max.) = 3.6 V (@V
CC
= 0 V to 3.6 V)
All outputs V
O
(Max.) = 3.6 V (@V
CC
= 0 V)
鈥?/div>
Output current
鹵2
mA (@V
CC
= 1.2 V)
鹵4
mA (@V
CC
= 1.4 V to 1.6 V)
鹵6
mA (@V
CC
= 1.65 V to 1.95 V)
鹵18
mA (@V
CC
= 2.3 V to 2.7 V)
鹵24
mA (@V
CC
= 3.0 V to 3.6 V)
鈥?/div>
Package type
Package type
SSOP-8 pin
Package code
TTP-8DB
Package suffix
US
Taping code
E (3,000 pcs / Reel)
