HD66137T

High-Voltage Durable 240-Channel Common Driver

for Dot-Matrix STN LCD

ADE-207-291(Z)

Rev. 2

Aug. 03, 1999

Description

The HD 66137T is a 240-channel common driver which drives a dot matrix STN LCD panel. By changing

the mode, this can be applied to 240- and 200- and 160- channel output. Through the use of a 43-V high-

voltage CMOS process technology, a high-voltage drive of +21.5 V and 鈥?1.5 V, centering on VM is

possible. 鈥?1.5V generated from +21.5 V with built-in switching circuit and external capacity. Low logic-

drive voltage (3 V) is used. This device is used together with the segment driver HD66130, HD66134ST or

HD66136.

Features

鈥?/div>

Display duty: Up to 1/240

LCD drive voltage: 43 V max

Built-in switching circuit (to generate 鈥?1.5 V)

Number of LCD drive circuit: 240

Operating voltage: 2.5 to 5.5 V

Intermediate voltage I/F

Built-in alternating signal generation circuit Pin programmable

Output mode change: 240-output mode

200-output mode

160-output mode

鈥?/div>

Built-in display-off function

鈥?/div>

Flex TCP

1
