HD49351BP/HBP
CDS/PGA & 10-bit A/D TG Converter
REJ03F0110-0100Z
Rev.1.0
Jul 06, 2004
Description
The HD49351BP/HBP is a CMOS IC that provides CDS-PGA analog processing (CDS/PGA) suitable for CCD camera
digital signal processing systems together with a 10-bit A/D converter and timing generator in a single chip. HD49351
has
deleted the
stripe mode, pd_mix mode,
and added the 5 鈥?6 pulse and H_msk2 - 4 as contrasted with HD49335.
There are address map and timing generator charts besides this specification. May be contacted to our sales department
if examining the details.
Functions
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Correlated double sampling
PGA
10-bit ADC
Timing generator
Operates using only the 3 V voltage
Corresponds to switching mode of power consumption and operating frequency
220 mW (Typ), maximum frequency: 36 MHz (HD49351HBP)
150 mW (Typ), maximum frequency: 25 MHz (HD49351BP)
鈥?/div>
ADC direct input mode
鈥?/div>
FBGA 65-pin package
Features
鈥?/div>
Suppresses low-frequency noise, which output from CCD by the correlated double sampling.
鈥?/div>
The S/H response frequency characteristics for the reference level can be adjusted using values of external parts and
registers.
鈥?/div>
High sensitivity is achieved due to the high S/N ratio and a wide dynamic range provided by a PG amplifier.
鈥?/div>
PGA, pulse timing, standby mode, etc., is achieved via a serial interface.
鈥?/div>
High precision is provided by a 10-bit-resolution A/D converter.
鈥?/div>
Difference encoded gray code can be selected as an A/D output code. It is effective in suppression of solarization
(wave pattern). It is patented by Renesas.
鈥?/div>
Timing generator generates the all of pulse which are needed for CCD driving.
Rev.1.0, Jul 06, 2004, page 1 of 28
