HD404669 Series

Low-Voltage AS Microcomputers with On-Chip DTMF

Generation Circuit

ADE-202-083B

Rev. 3.0

Sept. 1999

Description

The HD404669 Series microcomputers incorporate a DTMF generation circuit, two comparators, and a

serial interface on chip. They also provide input and output pins with large current handling capacities.

Thus they are 4-bit single-chip microcomputers that are optimal for use in multifunction telephones,

cordless telephones, and other communications equipment.

HD404669 Series microcomputers have a 32.768 kHz sub-oscillator for realtime clock use, providing a

time counting facility, and a variety of power supply modes to reduce current drain.

The HD407A4669 is a ZTAT鈩?microcomputer with on-chip PROM that drastically shortens development

time and ensures a smooth transition from debugging to mass production. (The PROM programming

specifications are the same as for the 27256 type.)
