HD29C3487
Quadruple Differential Line Drivers With 3 State Outputs
ADE-205-587 (Z)
1st. Edition
Dec. 2000
Description
The HD29C3487 features quadruple differential line drivers which satisfy the requirements of EIA standard
RS-422A. This device is designed to provide differential signals with high current capability on bus lines.
The enable input at low level permits the relate output in high impedance state. The output circuit has
active pull up and pull down and is capable of sinking or sourcing 20 mA.
Features
鈥?/div>
TTL input compatibility
鈥?/div>
Propagation delay time: 6 ns typ
鈥?/div>
Output to output skew: 0.5 ns typ
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High output impedance in power off conditions
Meets EIA standard RS-422A
Operates from a single 5 V supply
Three state outputs
鈥?/div>
Low power dissipation with CMOS process
鈥?/div>
Power up and power down protection
鈥?/div>
Pin to pin compatible with HD293487
