Total Power Dissipation (Tc=25擄C) .................................................................................... 40 W
鈥?/div>
Maximum Voltages and Currents
BVCBO Collector to Base Voltage ...................................................................................... 60 V
BVCEO Collector to Emitter Voltage................................................................................... 60 V
BVEBO Emitter to Base Voltage ........................................................................................... 5 V
IC Collector Current .............................................................................................................. 4 A
IB Base Current .................................................................................................................... 1 A
Electrical Characteristics
(Ta=25擄C)
Symbol
BVCBO
BVCEO
BVEBO
ICEO
ICBO
IEBO
*VCE(sat)
*VBE(on)
*hFE
Min.
60
60
5
-
-
-
-
-
750
Typ.
-
-
-
-
-
-
-
-
-
Max.
-
-
-
200
200
2
2.5
2.5
-
Unit
V
V
V
uA
uA
mA
V
V
Test Conditions
IC=1mA
IC=50mA
IE=1mA
VCB=30V
VCB=60V
VBE=5V
IC=1.5A, IB=30mA
IC=1.5A, VCE=3V
IC=1.5A, VCE=3V
*Pulse Test : Pulse Width
鈮?80us,
Duty Cycle鈮?%
HSMC Product Specification
1
2
