the unity gain stable HA-5102/883. This general purpose
鈮?/div>
1, and 8MHz band-
width (typ). Complementing these outstanding parameters is
a very low noise specification of 4.3nV/鈭欻z at 1kHz (typ),
6nV/鈭欻z (max).
Fabricated using the Intersil standard high frequency D.I.
process, these operational amplifiers also offer excellent
input specifications such as 2.5mV (max) offset voltage and
75nA (max) offset current. Complementing these specifica-
tions are 100dB (min) open loop gain and 60dB channel sep-
aration (min). Economically, the HA-5102/883 also
consumes a very moderate amount of supply power
180mW/ package.
This impressive combination of features make this amplifier
ideally suited for designs ranging from audio amplifiers and
active filters to the most demanding signal conditioning and
instrumentation circuits.
July 1994
Features
鈥?This Circuit is Processed in Accordance to MIL-STD-
883 and is Fully Conformant Under the Provisions of
Paragraph 1.2.1.
鈥?Low Input Noise Voltage Density at 1kHz . 6nV/鈭欻z (Max)
4.3nV/鈭欻z (Typ)
鈥?High Slew Rate . . . . . . . . . . . . . . . . . . . . . . . .1V/碌s (Min)
3V/碌s (Typ)
鈥?Unity Gain Bandwidth . . . . . . . . . . . . . . . . . 8MHz (Typ)
鈥?High Open Loop Gain (Full Temp) . . . . . 100kV/V (Min)
250kV/V (Typ)
鈥?High CMRR, PSRR (Full Temp). . . . . . . . . . . 86dB (Min)
100dB
(Typ)
鈥?Low Offset Voltage Drift . . . . . . . . . . . . . . 3碌V/
o
C (Typ)
鈥?No Crossover Distortion
鈥?Standard Dual Pinout
Applications
鈥?High Quality Audio Preamplifiers
鈥?High Q Active Filters
鈥?Low Noise Function Generators
鈥?Low Distortion Oscillators
鈥?Low Noise Comparators
Ordering Information
PART
NUMBER
HA2-5102/883
HA4-5102/883
HA7-5102/883
TEMPERATURE
RANGE
-55
o
C to +125
o
C
-55
o
C to +125
o
C
-55
o
C to +125
o
C
PACKAGE
8 Pin Can
20 Lead Ceramic LCC
8 Lead CerDIP
Pinouts
HA-5102/883
(CERDIP)
TOP VIEW
HA-5102/883
(CLCC)
TOP VIEW
OUT 1
HA-5102/883
(METAL CAN)
TOP VIEW
V+
NC
NC
1
2
3
4
-
+
1
2
-
+
8 V+
7 OUT2
6 -IN2
5 +IN2
NC
-IN1
NC
+IN1
NC
4
5
6
7
8
V+
OUT1
-IN1
+IN1
V-
NC
8
OUT1
18 NC
-IN1
2
1
1
-+
2
+ -
6 -IN2
7 OUT2
3
1
2
- +
1 20 19
2
17 OUT2
+ -
16 NC
15 -IN2
14 NC
+IN1
3
4
V-
5
+IN2
9
NC
10 11 12 13
V-
+IN2
NC
NC
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a trademark of Intersil Americas Inc.
Copyright 漏 Intersil Americas Inc. 2002. All Rights Reserved
Spec Number
109
511019-883
FN3709
