HA1-5104-2 Datasheet

  • HA1-5104-2

  • Dual and Quad, 8MHz and 60MHz, Low Noise Operational Amplifi...

  • 16頁

  • INTERSIL   INTERSIL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HA-5102, HA-5104, HA-5114
Data Sheet
April 1999
File Number
2925.4
Dual and Quad, 8MHz and 60MHz, Low
Noise Operational Ampli鏗乪rs
Low noise and high performance are key words describing
HA-5102, HA-5104 and HA-5114. These general purpose
ampli鏗乪rs offer an array of dynamic speci鏗乧ations ranging
from a 3V/碌s slew rate and 8MHz bandwidth (5102/04) to
20V/碌s slew rate and 60MHz gain-bandwidth-product
(HA-5114). Complementing these outstanding parameters is
a very low noise speci鏗乧ation of 4.3nV/鈭欻z at 1kHz.
Fabricated using the Intersil high frequency DI process,
these operational ampli鏗乪rs also offer excellent input
speci鏗乧ations such as a 0.5mV offset voltage and 30nA
offset current. Complementing these speci鏗乧ations are
108dB open loop gain and 60dB channel separation.
Consuming a very modest amount of power (90mW/
package for duals and 150mW/package for quads), HA-
5102/04/14 also provide 15mA of output current.
This impressive combination of features make this series of
ampli鏗乪rs ideally suited for designs ranging from audio
ampli鏗乪rs and active 鏗乴ters to the most demanding signal
conditioning and instrumentation circuits.
These operational ampli鏗乪rs are available in dual or quad
form with industry standard pinouts allowing for immediate
interchangeability with most other dual and quad operational
ampli鏗乪rs.
HA-5102
HA-5114
Dual, Comp.
HA-5104
Quad, Uncomp.
Quad, Comp.
Features
鈥?Low Noise. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.3nV/鈭欻z
鈥?Bandwidth. . . . . . . . . . . . . . . . . . . . 8MHz (Compensated)
60MHz (Uncompensated)
鈥?Slew Rate . . . . . . . . . . . . . . . . . . . . 3V/碌s (Compensated)
20V/碌s (Uncompensated)
鈥?Low Offset Voltage . . . . . . . . . . . . . . . . . . . . . . . . . 0.5mV
鈥?Available in Duals or Quads
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
High Q, Active Filters
Audio Ampli鏗乪rs
Instrumentation Ampli鏗乪rs
Integrators
Signal Generators
For Further Design Ideas, See Application Note AN554
Pinouts
HA-5102 (PDIP, CERDIP)
TOP VIEW
OUT1 1
-IN1 2
+IN1 3
V- 4
8 V+
-
+
-
+
7 OUT2
6 -IN2
5 +IN2
Refer to the /883 data sheet for military product.
HA-5104 (PDIP, CERDIP)
HA-5114 (PDIP)
TOP VIEW
OUT1 1
-IN1 2
1
4
14 OUT4
Ordering Information
TEMP. RANGE
PART NUMBER
(
o
C)
HA3-5102-5
HA7-5102-2
HA1-5104-2
HA1-5104-5
HA3-5104-5
HA9P5104-9
HA3-5114-5
HA9P5114-9
0 to 75
-55 to 125
-55 to 125
0 to 75
0 to 75
-40 to 85
0 to 75
-40 to 85
PACKAGE
8 Ld PDIP
8 Ld CERDIP
14 Ld CERDIP
14 Ld CERDIP
14 Ld PDIP
16 Ld SOIC
14 Ld PDIP
16 Ld SOIC
PKG. NO
E8.3
F8.3A
F14.3
F14.3
E14.3
M16.3
E14.3
M16.3
-
+
-
+
13 -IN4
12 +IN4
11 V-
+IN1 3
V+ 4
+IN2 5
-IN2 6
OUT2 7
+
-
+
-
10 +IN3
9 -IN3
8 OUT3
2
3
HA5104/5114 (SOIC)
TOP VIEW
OUT1 1
-IN1 2
+IN1 3
V+ 4
+IN2 5
-IN2 6
OUT2 7
NC 8
+
16 OUT4
1
-
+
4
-
+
15 -IN4
14 +IN4
13 V-
-
+
12 +IN3
11 -IN3
10 OUT3
9 NC
-
2
3
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Copyright
漏
Intersil Corporation 1999

HA1-5104-2 產品屬性

  • 25

  • 集成電路 (IC)

  • Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps

  • -

  • 通用

  • 4

  • -

  • 3 V/µs

  • -

  • 8MHz

  • 130nA

  • 500µV

  • 5mA

  • 15mA

  • ±5 V ~ 18 V

  • -55°C ~ 125°C

  • 通孔

  • 14-CDIP（0.300"，7.62mm）

  • 14-CERDIP

  • 管件
