HA-5340_03 Datasheet

  • HA-5340_03

  • 700ns, Low Distortion, Precision Sample and Hold Amplifier

  • 10頁

  • INTERSIL   INTERSIL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
HA-5340
Data Sheet
June 2003
FN2859.5
700ns, Low Distortion, Precision Sample
and Hold Amplifier
The HA-5340 combines the advantages of two sample/ hold
architectures to create a new generation of monolithic
sample/hold. High amplitude, high frequency signals can be
sampled with very low distortion being introduced. The
combination of exceptionally fast acquisition time and
specified/characterized hold mode distortion is an industry
first. Additionally, the AC performance is only minimally
affected by additional hold capacitance.
To achieve this level of performance, the benefits of an
integrating output stage have been combined with the
advantages of a buffered hold capacitor. To the user this
translates to a front-end stage that has high bandwidth due to
charging only a small capacitive load and an output stage with
constant pedestal error which can be nulled out using the
offset adjust pins. Since the performance penalty for
additional hold capacitance is low, the designer can further
minimize pedestal error and droop rate without sacrificing
speed.
Low distortion, fast acquisition, and low droop rate are the
result, making the HA-5340 the obvious choice for high
speed, high accuracy sampling systems.
Features
鈥?Fast Acquisition Time (0.01%) . . . . . . . . . . . . . . . . . 700ns
鈥?Fast Hold Mode Settling Time (0.01%) . . . . . . . . . . 200ns
鈥?Low Distortion (Hold Mode) . . . . . . . . . . . . . . . . . . -72dBc
(V
IN
= 200kHz, f
S
= 450kHz, 5V
P-P
)
鈥?Bandwidth Minimally Affected By External C
H
鈥?Fully Differential Analog Inputs
鈥?Built-In 135pF Hold Capacitor
Applications
鈥?High Bandwidth Precision Data Acquisition Systems
鈥?Inertial Navigation and Guidance Systems
鈥?Ultrasonics
鈥?SONAR
鈥?RADAR
Pinout
HA-5340 (SOIC)
TOP VIEW
-IN 1
+IN 2
16 S/H CONTROL
15 SUPPLY GND
14 NC
13 NC
EXTERNAL
12 HOLD CAP.
11 NC
10 NC
9 V+
Ordering Information
PART NUMBER
HA9P5340-5
TEMP.
RANGE (
o
C)
0 to 75
PACKAGE
16 Ld SOIC
PKG.
DWG. #
M16.3
OFFSET ADJ. 3
OFFSET ADJ. 4
NC 5
V- 6
Functional Diagram
ADJUST OFFSET
C
HOLD EXTERNAL
(OPTIONAL)
SIG. GND 7
OUTPUT 8
3
4
12
8
C
HOLD
120pF
-IN
+IN
S/H
CONTROL
1
2
16
9
V+
6
V-
15
7
C
COMP
15pF
8
OUT
SUPPLY SIGNAL GND
GND
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright 漏 Intersil Americas Inc. 2003. All Rights Reserved.
All other trademarks mentioned are the property of their respective owners.
