HA-5137A Datasheet

  • HA-5137A

  • 63MHz, Ultra-Low Noise Precision Operational Amplifier

  • 537.22KB

  • 9頁

  • INTERSIL   INTERSIL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HA-5137A
TM
Data Sheet
April 2000
File Number
2908.5
63MHz, Ultra-Low Noise Precision
Operational Ampli鏗乪r
The HA-5137 operational ampli鏗乪r features an unparalleled
combination of precision DC and wideband high speed
characteristics. Utilizing the Intersil Dielectric Isolation
technology and advanced processing techniques, this
unique design unites low noise
(
3nV
鈦?/div>
Hz
)
precision
instrumentation performance with high speed (20V/碌s)
wideband capability.
This ampli鏗乪r鈥檚 impressive list of features include low V
OS
(10碌V), wide gain bandwidth (63MHz), high open loop gain
(1800V/mV), and high CMRR (126dB). Additionally, this
鏗俥xible device operates over a wide supply range (鹵5V to
鹵20V)
while consuming only 140mW of power.
Using the HA-5137 allows designers to minimize errors while
maximizing speed and bandwidth in applications requiring
gains greater than 鏗乿e.
This device is ideally suited for low level transducer signal
ampli鏗乪r circuits. Other applications which can utilize the
HA-5137鈥檚 qualities include instrumentation ampli鏗乪rs, pulse
or RF ampli鏗乪rs, audio preampli鏗乪rs, and signal conditioning
circuits.
This device can easily be used as a design enhancement by
directly replacing the 725, OP25, OP06, OP07, OP27 and
OP37 where gains are greater than 鏗乿e. For the military
grade product, refer to the HA-5137/883 data sheet.
Features
鈥?Slew Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20V/碌s
鈥?Wide Gain Bandwidth (A
V
鈮?/div>
5) . . . . . . . . . . . . . . . 63MHz
鈥?Low Noise. . . . . . . . . . . . . . . . . . . . . . .
3nV/ Hz
at 1kHz
鈥?Low V
OS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10碌V
鈥?High CMRR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126dB
鈥?High Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1800V/mV
Applications
鈥?High Speed Signal Conditioners
鈥?Wide Bandwidth Instrumentation Ampli鏗乪rs
鈥?Low Level Transducer Ampli鏗乪rs
鈥?Fast, Low Level Voltage Comparators
鈥?Highest Quality Audio Preampli鏗乪rs
鈥?Pulse/RF Ampli鏗乪rs
鈥?For Further Design Ideas See Application Note AN553
Ordering Information
PART NUMBER
HA7-5137A-5
TEMP.
RANGE (
o
C)
0 to 75
PACKAGE
8 Ld CERDIP
PKG.
NO.
F8.3A
Pinout
HA-5137A
(CERDIP)
TOP VIEW
BAL
-IN
+IN
V-
1
2
3
4
-
+
8
7
6
5
BAL
V+
OUT
NC
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil and Design is a trademark of Intersil Corporation.
|
Copyright
漏
Intersil Corporation 2000
