Fast Speed Switching Time
SOD-323 Plastic Package
Absolute Maximum Ratings
Rating
Continuous Reverse Voltage
Peak Forward Current
Peak Forward Surge Current
Symbol
VR
IF
IFM(surge)
Value
100
200
500
Unit
Vdc
mAdc
mAdc
Thermal Characteristics
Characteristic
Total Device Dissipation FR-5 Board
(Note1)
Ta=25擄C
Derate above 25擄C
Thermal Resistance Junction to Ambient
Total Device Dissipation Alumina Substrate
(Note2)
Ta=25擄C
Derate above 25擄C
Thermal Resistance Junction to Ambient
Junction and Storage Temperature Range
Note1: FR-5=1.0X0.75X0.062 in.
Note2: Alumina=0.4X0.3X0.024 in. 99.5% alumina
Symbol
PD
R胃JA
PD
R胃JA
Tj, Tstg
Max
225
1.8
556
Unit
mW
mW/擄C
擄C/W
mW
300
2.4
mW/擄C
417
擄C/W
-55~+150
擄C
Electrical Characteristics
(Ta=25擄C, unless otherwise noted)
Characteristic
Off Characteristics
Reverse Breakdown Voltage (IBR=100uAdc)
Reverse Voltage Leakage Current (VR=20Vdc)
Reverse Voltage Leakage Current (VR=75Vdc)
Forward Voltage (IF=10mAdc)
Diode Capacitance(VR=0Vdc, f=1MHz)
Reverse Recovery Time(IF=IR=10mAdc)
Symbol
V(BR)
IR
VF
CD
trr
Min
100
-
-
-
-
-
Max
-
25
5
1000
4
4
Unit
Vdc
nAdc
uAdc
mVdc
pF
ns
H4148SL
HSMC Product Specification
1
2
