10/100BASE-T QUAD PORT
SURFACE MOUNT MAGNETICS
Meets IEEE 802.3 specification
IC grade transfer-molded package withstands
245擄C peak temperature profile
Electrical Specifications @ 25擄C 鈥?Operating Temperature 0擄C to 70擄C
Part
Number
H1092NL
2d
Transmit
Turns Ratio
Pri-Sec
Return Loss
(dB TYP)
2-30 MHz 40 MHz
50 MHz
60-80 MHz
Crosstalk
(dB TYP)
1 MHz 30 MHz 60 MHz 100 MHz
Common to Common
Rejection Ratio
0.1-60 MHz
(dB MIN)
Transmit
Receive
-35
Differential to
Common Mode
Rejection
(dB MIN)
0.1-60 MHz 60-200 MHz
-40
-30
2:1
-18
-16
-14
-12
-60
-50
-40
-35
-35
NOTE:
All models meet breakdown (Hipot) of 1500 Vrms. Insertion Loss at 0.1-100 MHz is typically 0.5 dB.
1. For Tape & Reel packaging, add suffix 鈥淭鈥?to the end of the part number when ordering, e.g. H10 92NLT.
2. MSL = Moisture Sensitivity: Level a = 1, b = 2, c = 3, d = 4, e = 5.
Mechanical
H1092NL
1.125 MAX
28,58
.090
40X 2,29
DATE CODE
COUNTRY OF ORIGIN
.640 MAX
16,26
.480
12,19
.050
19X 1,27
.950
24,13
40X .018
0,46
.050
1,27
19X .050 = .950
1,27
24,13
40X .030
0,76
.485
12,32
0擄 聳 8擄
.230 MAX
5,84
.045
40X 1,14
.004/0,10
40 Surfaces
40X .024
0,61
.010
_
.005
+
0,25 0,13
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are 鹵 .010
0,25
USA 858 674 8100
鈥?/div>
Germany 49 7032 7806 0
鈥?/div>
Singapore 65 6287 8998
鈥?/div>
Shanghai
86 21 32181071
鈥?/div>
China 86 755 33966678
鈥?/div>
Taiwan 886 3 4641811
www.pulseeng.com
1
H313.B (9/07)
