GT605
THRU
GT610
6.0 AMPS. Glass Passivated Rectifiers
Voltage Range
50 to 1000 Volts
Current
6.0 Amperes
Features
Low forward voltage drop
High current capability
High reliability
High surge current capability
GT
Mechanical Data
Cases: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Terminals, solderable per MIL-
STD-202, Method 208 guaranteed
High temperature soldering guaranteed:
260鈩?10 seconds at 5 lbs.,(2.3kg)
tension
Weight: 3.46 grams
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25鈩僡mbient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol
GT
GT
Type Number
605
61
Maximum Recurrent Peak Reverse Voltage
50 100
V
RRM
Maximum RMS Voltage
35
70
V
RMS
Maximum DC Blocking Voltage
50 100
V
DC
Maximum Average Forward Rectified Current
@T
A
= 60鈩?/div>
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 6.0A
Maximum DC Reverse Current @ T
A
=25鈩?/div>
at Rated DC Blocking Voltage @ T
A
=125鈩?/div>
GT
62
GT
64
GT
66
GT
68
GT
610
Units
V
V
V
A
A
V
uA
uA
pF
鈩?/div>
鈩?/div>
200
140
200
400
280
400
6.0
250
1.0
600
420
600
800 1000
560 700
800 1000
I
(AV)
I
FSM
V
F
I
R
10
100
Typical Junction Capacitance ( Note )
Cj
100
Operating Temperature Range
T
J
-65 to +150
Storage Temperature Range
T
STG
-65 to +150
Note: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
- 482 -
