GS9068+ Datasheet

  • GS9068+

  • Cable Driver for SD-SDI & DVB-ASI. 3.3V supply.

  • 7頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

GS9068
SD SDI Cable Driver
DATA SHEET
KEY FEATURES
鈥?SMPTE 259M and SMPTE 344M compliant
鈥?dual coaxial cable driving outputs
鈥?50鈩?differential PECL input
鈩?/div>
鈥?single 3.3V power supply operation
鈥?space-saving 8-lead SOIC
鈥?operating temperature range: 0擄C to 70擄C
鈥?pin compatible with GS1528 HD-LINX
鈩?/div>
II multirate SDI
dual slew-rate cable driver
APPLICATIONS
鈥?/div>
SMPTE 259M Coaxial Cable Serial Digital Interfaces
DESCRIPTION
The GS9068 is a second generation high-speed bipolar
integrated circuit designed to drive one or two 75鈩?co-axial
cables at data rates up to 540Mb/s.
The GS9068 accepts a LVPECL level differential input,
which may be AC coupled. External biasing resistors at the
inputs are not required.
Power consumption is typically 160mW using a +3.3V DC
power supply.
GS9068
BANDGAP REFERENCE AND BIASING CIRCUIT
R
SET
SDI
SDI
INPUT
DIFFERENTIAL
PAIR
SDO
OUTPUT STAGE &
CONTROL
SDO
GS9068 FUNCTIONAL BLOCK DIAGRAM
Revision Date: March 2003
GENNUM CORPORATION P.O. Box 489, Stn. A, Burlington, Ontario, Canada L7R 3Y3
Tel. +1 (905) 632-2996 Fax. +1 (905) 632-5946 E-mail: info@gennum.com
www.gennum.com
Document No. 22213 - 1
