V.C. Preamp Hybrid
for Class D
GS3015 - HYB DATA SHEET
FEATURES
鈥?Gennum's GL504 preamp
鈥?mounts on back of Microtronic PJ88S VC Socket
鈥?low external parts count
鈥?designed to drive Class D integrated receivers
鈥?adjustable peak clipper
鈥?low current drain (150
碌
A) typical
鈥?low noise and distortion
DESCRIPTION
The GS3015 incorporates Gennum's GL504 preamp, three of
the required capacitors and a mid supply referencing 48K
resistor. All that is required for a fully functional hearing aid
system is the addition of a microphone, receiver, volume
control, interstage coupling capacitor and an MPO adjusting
potentiometer.
The GS3015 has been designed to mount on the back of the
Microtronics PJ88S Socket Volume Control. This translates to
a saving in space within the hearing instrument, as the circuitry
mounts directly beneath the volume control. If the VC requires
replacing, it is a simple procedure to remove the defective unit
from the socket and install a new device. This does not disturb
the electronic circuitry.
The major advantage of the GL504 over other preamplifiers is
the electronic MPO adjustment. Since conventional MPO is not
possible in a class D receiver, Gennum provides it in the
preamp.
STANDARD PACKAGING
鈥?Hybrid Typical Dimensions
0.192 in x 0.194 in x 0.113 in
(4.88 mm x 4.93 mm x 2.85 mm)
10 V
B
R
MIC
V
MIC
2
C1 6
3碌3
7
R
PULL
C3
47n
8
1 B
OUT
4 V
REC
A
IN
11
C2
47n
-A
5
-B
R1
48K
4
3
1
2
3
C
IN
6
CT
5
7
A
OUT
B
IN
8
GND MPO
9
GS3015
HYBRID
All resistors in ohms, all capacitors
in farads unless otherwise stated
BLOCK DIAGRAM
Revision Date: May 1998
Document No. 520 - 92 - 05
GENNUM CORPORATION P.O. Box 489, Stn. A, Burlington, Ontario, Canada L7R 3Y3 tel. +1 (905) 632-2996
Web Site: www.gennum.com E-mail: hipinfo@gennum.com
