GP2Y0A21YK/GP2Y0D21YK
I
Features
GP2Y0A21YK/
GP2Y0D21YK
Distance judgement type :
GP2Y0D21YK
Judgement distance : 24cm
(Adjustable within the range of 10 to 80cm [Optionally available])
General Purpose Type Distance
Measuring Sensors
I
Outline Dimensions
(Unit : mm)
1. Less influence on the color of reflective objects, reflectivity
2. Line-up of distance output/distance judgement type
Distance output type (analog voltage) :
GP2Y0A21YK
Detecting distance : 10 to 80cm
4.5
蠁3.2
hole
R3.75
3.75
Light emitter side 10.1
#
37
29.5
#
20鹵0.1
Light detector side
6.3
R3.75
2
+0.5
18.9
鈭?.3
Lens case
8.4
7.2
3. External control circuit is unnecessary
4. Low cost
蠁3.2
hole
Connector 1.2
Made by
3.3
J.S.T. MFG,
CO., LTD.
S3B-PH
2-1.5
13.5
13
I
Applications
1. TVs
2. Personal computers
3. Cars
4. Copiers
7.5
PWB
14.75
4.15
16.3
1
3
I
Absolute Maximum Ratings
Parameter
Supply voltage
Output terminal voltage
Operating temperature
Storage temperature
Terminal connection
鉂?/div>
The dimensions marked are
described the dimensions of
lens center position.
鉂?/div>
Unspecified tolerance :
鹵0.3mm
#
(T
a
=25藲C,
V
CC
=5V)
Symbol
Rating
Unit
V
CC
鈭?.3
to
+7
V
V
O
鈭?.3
to V
CC
+0.3
V
T
opr
鈭?0
to
+60
藲C
T
stg
鈭?0
to
+70
藲C
1
2
3
V
O
GND
V
CC
Notice
In the absence of confirmation by device specification sheets, SHARP takes no responsibility for any defects that may occur in equipment using any SHARP
devices shown in catalogs, data books, etc. Contact SHARP in order to obtain the latest device specification sheets before using any SHARP device.
Internet Internet address for Electronic Components Group http://sharp-world.com/ecg/
