GP1F562T series
General Description
Fiber Optic Transmitter/Receiver
Outline Dimensions
GP1F562T
蠁
3
.6
10.8
4.4
Thin Type Optical Mini-jack for Digital Audio Equipment
(Unit : mm)
2.3
Sharp's
GP1F562T/GP1F565R/GP1F595R
are thin type,
transmitter/receiver unit for compact optical mini-jack.
It is suitable for signal transmission in portable digital audio
equipment(MD player) due to thin(4.4mm), low voltage
operation and low dissipation current.
18.0
蠁5.5
Features
(1) Compact (adoption of compact jack for mini plug)
EIAJ RC-6701A
(2) Thin type (4.4mm)
(3) Can distinguish and transmit both of optical signal
and electrical signal
(4) High speed data transmission
Signal transmission speed : MAX. 8Mbps(NRZ signal)
(5) Low voltage operation
(GP1F562T/565R : 2.7 to 3.6V)
(GP1F595R : 2.4 to 3.0V)
(6) Low dissipation current
(7) Minimum input optical power level approved by
EIAJ standard (CP-1201)
(8) Optic transmitter unit :
GP1F562T
Optic receiver unit :
GP1F565R/GP1F595R
Applications
(1) MD players
(2) Portable CD players
1
6
5
6
4
3
1
2
3
4
5
6
7
8
9
10
Jack terminal
2
7 8
10
9
Device terminal
2.54
2.54
.6
GP1F565R
/GP1F595R
10.8
4.4
蠁
3
18.0
蠁5.5
5
1
2
3
4
5
6
7
8
9
2.3
1
6
6
4
3
2
7
8
9
Jack terminal
Device terminal
2.54
2.54
Jack terminal configuration
GP1F562T
5(e)
4(d)
2(a)
3(b)
1(c)
Drive
IC
8 Vcc
7 Vin
9 GND
10 NC
GP1F565R/595R
5(e)
4(d)
2(a)
3(b)
1(c)
7 Vcc
9 Vout
8 GND
(Internal connection)
OPIC light detector
(Notice)
