GM71V16403C

GM71VS16403CL

4,194,304 WORDS x 4 BIT

CMOS DYNAMIC RAM

Description

The GM71V(S)16403C/CL is the new

generation dynamic RAM organized 4,194,304

words x 4 bit. GM71V(S)16403C/CL has

realized higher density, higher performance and

various functions by utilizing advanced CMOS

process technology. The GM71V(S)16403C/CL

offers Extended Data Out (EDO) Page Mode as

a high speed access mode. Multiplexed address

inputs permit the GM71V(S)16403C/CL to be

packaged in a standard 300 mil 24(26) pin SOJ,

and a standard 300 mil 24(26) pin plastic TSOP

II. The package size provides high system bit

densities and is compatible with widely available

automated testing and insertion equipment.

System oriented features include single power

supply 3.3V +/- 0.3V tolerance, direct

interfacing capability with high performance

logic families such as Schottky TTL.

Features

* 4,194,304 Words x 4 Bit Organization

* Extended Data Out Mode Capability

* Single Power Supply (3.3V +/- 0.3V)

* Fast Access Time & Cycle Time

(Unit: ns)

t

RAC

t

CAC

GM71V(S)16403C/CL-5

GM71V(S)16403C/CL-6

GM71V(S)16403C/CL-7

50

60

70

13

15

18

t

RC

84

104

124

t

HPC

20

25

30

* Low Power

Active : 324/288/252mW (MAX)

Standby : 7.2mW (CMOS level : MAX)

: 0.36mW (L-version : MAX)

* RAS Only Refresh, CAS before RAS Refresh,

Hidden Refresh Capability

* All inputs and outputs TTL Compatible

* 4096 Refresh Cycles/64ms

* 4096 Refresh Cycles/128ms (L-version)

* Self Refresh Operation (L-version)

* Battery Backup Operation (L-version)

* Test Function : 16bit parallel test mode

Pin Configuration

24(26) SOJ

V

CC

I/O1

I/O2

WE

RAS

A11

A10

A0

A1

A2

A3

V

CC

1

2

3

4

5

6

26

25

24

23

22

21

24(26) TSOP II

V

SS

I/O4

I/O3

CAS

OE

A9

A8

A7

A6

A5

A4

V

SS

V

CC

I/O1

I/O2

WE

RAS

A11

A10

A0

A1

A2

A3

V

CC

1

2

3

4

5

6

26

25

24

23

22

21

V

SS

I/O4

I/O3

CAS

OE

A9

A8

A7

A6

A5

A4

V

SS

8

9

10

11

12

13

19

18

17

16

15

14

8

9

10

11

12

13

19

18

17

16

15

14

(Top View)

Rev0.1/Apr鈥?1
