GHR16
New Product
Vishay Semiconductors
formerly General Semiconductor
Reverse Voltage
1600V
Forward Current
0.5A
Photoflash Rectifier
Case Style R-1
0.025 (0.65)
DIA.
0.021 (0.55)
0.787 (20.0)
MIN.
Features
鈥?Fast switching
鈥?Low leakage
鈥?High forward surge current capability
0.126 (3.2)
0.106 (2.7)
0.102 (2.6)
DIA.
0.091 (2.3)
Mechanical Data
Case:
R-1 molded epoxy with UL94V-0 flammability
classification
Polarity:
Color band denotes cathode end
Weight:
0.0073 oz., 0.2 g
Terminals:
High temperature soldering guaranteed:
260擄C/10 seconds, 0.375" (9.5mm) lead length, 5 lbs.
(2.3kg) tension
0.787 (20.0)
MIN.
Dimensions in inches and (millimeters)
Maximum Ratings & Thermal Characteristics
Ratings at 25擄C ambient temperature unless otherwise specified.
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375鈥?(9.5mm) lead length at T
A
= 55擄C
Peak forward surge current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum full load reverse current, full cycle average,
0.375鈥?(9.5mm) lead length at T
L
= 55擄C
Operating junction and storage temperature range
Symbol
V
RRM
V
RMS
V
DC
l
F(AV)
I
FSM
I
R(AV)
T
J
, T
STG
Value
1600
1120
1600
500
20
100
鈥?5 to +175
Unit
V
V
V
mA
A
碌A(chǔ)
擄C
Electrical Characteristics
Parameter
Ratings at 25擄C ambient temperature unless otherwise specified.
Symbol
V
F
I
R
t
rr
C
J
Value
1.5
5.0
300
10
Unit
V
碌A(chǔ)
ns
pF
Maximum instantaneous forward voltage drop at 0.5A
Maximum DC reverse current
at Rated DC blocking voltage at T
A
= 25擄C
Maximum reverse recovery time
at I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A
Typical junction capacitance at 4.0V, 1MHz
Document Number 88618
22-Feb-02
www.vishay.com
1
