QLogic Corporation
GEM312 Guardian Enclosure Management
Controller
Data Sheet
Features
s
s
s
s
s
s
s
s
s
s
s
s
s
Low-cost, single-chip solution for comprehensive
management of server and storage enclosures
Compliance with
SCSI Accessed Fault Tolerant
Enclosures
(SAF-TE) speci鏗乧ation, version 1.00
and addendum
Multimode, low voltage differential (LVD) SCSI
(on-chip, 48 mA and LVD SCSI transceivers)
Implemented as a standard SCSI target for easy
integration and compatibility
Eight bit, asynchronous SCSI data transfers
Wide SCSI addressing with hardware assigned
SCSI ID
Support for 鏗俛sh ROM
Reports enclosure con鏗乬uration and status
Automatic noti鏗乧ation of an environmental failure
Monitors storage devices, fans, power supplies, and
temperature
Controls indicators (for example, LEDs and audible
alarms)
Connects to the host using a standard, single-ended
SCSI cable
Vendor programmable operating con鏗乬uration
Product Description
The GEM312 is a low-cost, single-chip enclosure
management controller for servers and mass storage
subsystems. It supports the Ultra2 (LVD) speci鏗乧ation and
provides a rich set of features and functions for monitoring
and managing enclosures. The GEM312 supports the SCSI
SAF-TE speci鏗乧ation.
The GEM312 features support for 12 drive slots,
6 power supplies, 6 fans, and 4 digital temperature sensors.
An I
2
C serial interface and two general purpose output bits
provide additional interface 鏗俥xibility.
Operating con鏗乬uration is vendor programmable,
allowing the use of a single GEM312-based enclosure in a
variety of system con鏗乬urations.
The GEM312 block diagram is illustrated in 鏗乬ure 1.
GEM312
RESET
CLK
MEMORY
EPROM
OR
FLASH
TIMER
I
2
C
TEMP SENSORS AND
PASS-THRU DATA
TWO-WIRE
INTERFACE
CONTROL
LED/ADR OUTPUTS
SAF-TE
REGISTERS
CPU
SCSI
TARGET
INTERFACE
ID_ON
SCSI BUS
ENCLOSURE STATUS
鈥?FAN STATUS
鈥?POWER SUPPLY STATUS
鈥?DEVICE PRESENT
鈥?TEMP. OUT OF RANGE
STATUS
SEND GLOBAL OUTPUTS
鈥?ENCLOSURE POWER
鈥?ALARM
鈥?FAIL
Figure 1. GEM312 Block Diagram
32312-580-00 A
